1435-I Dunbier Centreline Series Alloy Wheel 13" 5/114.3 and Tyre 175Rlt13 | Marine Trailer Part

🔧 Product Description

Genuine Dunbier Marine Products Centreline-Series Alloy Wheel and Tyre 13" - 175RLT13 - Part Number: 1435-I

A complete 13-inch Centreline-series alloy trailer wheel fitted with a 175RLT13 radial light-truck tyre. The 5 × 114.3mm stud pattern suits compatible Ford-pattern marine-trailer hubs.

⚙️ Key Features

• Complete tyre-and-wheel assembly ready for compatible trailer hubs

• Marine-trailer wheel finish or alloy design as specified

• Commercial/light-truck or trailer radial tyre construction where stated

• Suitable for use as a road wheel or matched spare when specifications agree

• Factory-assembled combination avoids separate tyre fitting before installation

📏 Specifications

• Rim size: 13" alloy

• Tyre size: 175RLT13

• Stud pattern: 5 stud × 114.3mm PCD

• Published assembly capacity: approximately 690kg; confirm wheel and tyre markings

• Wheel finish/style: Centreline-series alloy

• Tyre brand, tread pattern, load index and speed symbol may vary with current supply; sidewall markings govern the supplied tyre

🔄 Cross Reference & Related Parts

🚤 Compatibility & Application

• Confirm rim diameter and width, stud count, pitch-circle diameter, centre bore, offset/backspacing and wheel-nut seat

• Check tyre clearance to guards, brakes, suspension and trailer frame through full travel

• The safe load is limited by the lowest rating of the tyre, rim, hub, bearings, axle, suspension and trailer placard

• Inflate only to the pressure required by the supplied tyre, load and trailer manufacturer

• Wheel nuts must be tightened in sequence to the specified torque and rechecked after the initial short trip

🔌 Function

Supports the trailer load, transmits braking and cornering forces and provides the road-contact surface for the trailer.

Common signs of wear, damage or replacement required:

• Tyre sidewall cracking, bulges, cuts or exposed cords

• Tread is worn unevenly, aged or below the legal limit

• Rim is cracked, buckled or corroded around the bead or stud holes

• Wheel loses pressure or develops vibration

• Stud holes elongate or wheel nuts no longer retain torque

📦 Condition

• Genuine Dunbier Marine Products part

• Brand new

• Supplied in original or equivalent packaging
