3306 Dunbier Pad Bracket 190 Long x 20mm (Round Leg) | Marine Trailer Part

🔧 Product Description

Dunbier Galvanised Pad Bracket with 190mm × 20mm Round Leg - Part Number: 3306

A galvanised adjustable support bracket for mounting a trailer bunk, plastic pad or timber support above a compatible crossmember. The 190mm-long, 20mm round leg allows support height and hull contact angle to be set while the upper U-bracket accepts a 50mm square member or suitable timber pad.

⚙️ Key Features

• 190mm round support leg

• 20mm leg diameter

• Upper bracket suits a 50mm square tube or timber pad

• Galvanised bolts and nuts included

• Adjustable replacement for trailer hull-support assemblies

📏 Specifications

• Leg length: 190mm

• Leg diameter: 20mm round

• Upper support: approximately 50mm square tube or timber pad

• Finish: galvanised

• Fasteners: included as supplied

🔄 Cross Reference & Related Parts

• Dunbier: 3306

• Shorter 120mm round-leg bracket: Dunbier 3304

• Related centreline plastic pad: Dunbier 3346

• Comparable brackets must match leg diameter, U-bracket width and crossmember mount

🚤 Trailer Compatibility & Application

• Suitable for Dunbier pad, bunk and centreline support arrangements using a 20mm round leg

• The receiving slide bracket or clamp must match the 20mm round leg

• Final height must distribute hull load across adjacent supports

🔌 Function

Positions and supports a bunk or pad at the required height and angle beneath the hull.

Common signs of wear or failure:

• Bracket is bent or twisted

• Leg is deeply corroded

• Bolt holes are elongated

• Pad moves after adjustment

• Bracket contacts the hull or trailer frame

🛠️ Installation & Safety

• Support the boat before loosening any loaded bracket

• Use all supplied washers and locking hardware

• Set adjacent pads to share the hull load evenly

• Maintain clearance from axles, springs and keel rollers

• Recheck fasteners after the first launch/retrieval cycle

📦 Condition

• Genuine Dunbier Marine Products part

• Brand new

• Supplied as one 190mm × 20mm round-leg pad bracket with hardware

• Supplied in original or equivalent packaging
