866457 Charge Air Cooler | Genuine Volvo Penta Part

866457 Charge Air Cooler | Genuine Volvo Penta Part

$7,757.65 AUD
$7,757.65 AUD
Sale Sold out
Shipping calculated at checkout.

Available on request — contact us

As an authorised Volvo Penta dealer we can source parts through channels not shown online, and check supersession and used options for you

Availability checked daily with Volvo Penta

🔧 Product Description

Genuine Volvo Penta charge air cooler from the Cooling System group, weighing 28.122 kg and listed for 24 applications across TWD, TID, TD and TAD series engines. It supersedes part number 424808, which was catalogued earlier as an intercooler. Three further charge air coolers appear in this listing - 866090, 866093 and 866178 - so order against the engine designation. It is a water-to-air cooler with its own core and end cover arrangement.

🚤 Compatibility

  • Engine Family: TWD, TID, TD, TAD

Full model list at the end of this description.

⚙️ Key Features

  • 28.122 kg
  • 24 applications across TWD, TID, TD and TAD series engines
  • Supersedes 424808, formerly listed as an intercooler
  • Cooling System group
  • Water-to-air core with its own end cover arrangement

🔌 Function

Cools the compressed air leaving the turbocharger before it reaches the inlet, so a denser charge with more oxygen in it enters the cylinders.

⚠️ Common Signs of Failure

  • Loss of power and black smoke under load
  • Charge air temperature running higher than it should
  • Oil collecting in the cooler or in the pipework below it
  • Coolant loss, or oil and coolant mixing, on a liquid-cooled unit
  • Fins bent, blocked or corroded away, or a leak found on pressure test

🛠️ Service Notes

  • The number this replaces was listed as an intercooler, so a search on the old term will find the same component
  • At over 28 kg this is a freight-scale item and needs proper support to fit
  • Pressure test the replacement before commissioning and flush the connecting pipework of any oil

🔄 Supersession & Cross Reference

OEM Supersession Chain

  • 866457 → Supersedes 424808 → Supersedes 469811

OEM / Related Numbers

  • 424808 earlier number superseded by this part
  • 469811 earlier number superseded by this part

📦 Condition

  • Genuine Volvo Penta part
  • Brand new
  • Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

  • Volvo Penta TID162AG, TID162AGP, TID162AP, TID162APB
  • Volvo Penta TWD1210G, TWD1210P, TWD1210V
  • Volvo Penta TWD1211V, TWD1211P, TWD1211G
  • Volvo Penta TWD1630G, TWD1630P, TWD1630V
  • Volvo Penta TAD1631GE, TAD1631G
  • Volvo Penta TWD1230ME, TWD1230VE
  • Volvo Penta TD164KAE
  • Volvo Penta TWD1010G
  • Volvo Penta TWD1030ME
  • Volvo Penta TWD1031VE
  • Volvo Penta TWD1231VE
  • Volvo Penta TWD1240VE
  • Volvo Penta TWD1620G
