0176214 0765183 Evinrude/Johnson 13 1/4 x 17 Aluminium Propeller | Genuine Used Part

🔧 Product Description

Genuine Evinrude Johnson 13 1/4 x 17 Aluminium Propeller - Part Number: 0176214 / 0765183

A genuine used three-blade right-hand aluminium propeller for Evinrude, Johnson and compatible OMC 13-spline large-gearcase applications.

The current service propeller 0765183 is nominally 13 1/4 inches in diameter with 17 inches of pitch. It uses the 4 1/4-inch thru-hub-exhaust gearcase and 13-tooth propeller shaft used across the identified outboard, Sea Drive and OMC sterndrive families. Some period replacement charts describe intermediate propeller 0177131 as 14 x 17, so the diameter stamped on the supplied used propeller should be checked before purchase.

⚙️ Key Features

• Genuine BRP / Evinrude / Johnson OEM aluminium propeller

• Correct current service part number 0765183

• Three blades, right-hand rotation and 17-inch pitch

• 13-spline hub for the 4 1/4-inch large gearcase

• Suitable for general recreational use where a 17-pitch propeller produces the correct full-throttle RPM

🔄 Supersession & Cross Reference

OEM Supersession Chain:

• 0765183 → Supersedes 0177131

• 0177131 → Supersedes 0176214

• 0176214 earlier OEM propeller reference

OEM / Related Numbers:

• 0176214

• 176214

• 0177131

• 177131

• 0765183

• 765183

• 0763463

• 763463

• 0391199

• 391199

• 0382764

• 382764

• 0765796 related stainless-steel 17-pitch performance alternative

Aftermarket / Verified Equivalents:

• Michigan Wheel Match: 011003 - 13 1/4 x 17 three-blade aluminium

• Michigan Wheel Match: 011024 - 14 x 17 three-blade aluminium alternative

• Solas Amita 3: 2411-133-17 - 13 1/4 x 17 three-blade aluminium

• Solas Rubex 3: 9411-133-17 with RBX-106 hub - 13 1/4 x 17 modular aluminium

• Turning Point Hustler: 21431711 with hub kit 11500300 - 13 1/4 x 17 aluminium

• Propco: J2-17P / J2-17SP - 13 1/4 x 17 aluminium replacement families

🚤 Compatibility

Commonly used on:

• Evinrude and Johnson 4 1/4-inch large-gearcase outboards with 13-spline propeller shafts

• OMC Sea Drive and OMC Model 400 / Cobra sterndrives using the 13-spline 4 1/4-inch gearcase

Typically suits:

• Engine models:

• Evinrude E-TEC 40HP, 50HP and 60HP - 2004 onward

• Johnson / Evinrude 45HP Commercial - 1986 onward

• Johnson / Evinrude 50HP pleasure and Commercial - 1971-1974

• Johnson / Evinrude 50HP three-cylinder pleasure - 1994-1998

• Johnson / Evinrude 55HP pleasure - 1968-1969

• Johnson / Evinrude 55HP Commercial - 1980 onward

• Evinrude E-TEC 55HP - 2009 onward

• Johnson / Evinrude 60HP three-cylinder pleasure - 1970-1971 and 1986-2001

• Johnson / Evinrude 60HP four-stroke - 1998 onward where the 13-spline gearcase is fitted

• Evinrude E-TEC 60HP - 2004 onward

• Johnson / Evinrude 65HP pleasure - 1972-1973

• Johnson / Evinrude 65HP Commercial - 1984-2001

• Evinrude 65HP Pontoon Series - 2014 onward

• Johnson / Evinrude 70HP pleasure and Commercial - 1974-2001

• Johnson / Evinrude 70HP four-stroke - 1998 onward where the 13-spline gearcase is fitted

• Johnson / Evinrude 75HP pleasure - 1975-1984

• Evinrude E-TEC 75HP - 2004 onward

• Johnson / Evinrude 85HP V4 - 1969-1980 and 1991-1995

• Johnson / Evinrude 88HP V4 - 1981-1996

• Johnson / Evinrude 90HP V4 - 1981 onward

• Evinrude E-TEC 90HP - 2004 onward with the 13-spline gearcase

• Johnson / Evinrude 100HP V4 - 1979-1980 and 1988-1993

• Johnson / Evinrude 110HP V4 - 1986-1989

• Johnson / Evinrude 112HP V4 - 1994-1996

• Johnson / Evinrude 115HP and 115 H.O. V4 - 1973 onward

• Evinrude E-TEC 115HP and 115 H.O. - 2004 onward with the 13-spline gearcase

• Johnson / Evinrude 120HP V4 - 1986-1994

• Johnson / Evinrude 125HP V4 - 1971-1972

• Evinrude E-TEC 130HP - 2009-2010 with the 20-inch / 13-spline gearcase

• Johnson / Evinrude 135HP V4 - 1973-1976

• Johnson / Evinrude 140HP V4 - 1977-1984 and 1986-1994

• OMC Sea Drive 1.6L V4 - 1982 onward with the 13-spline 4 1/4-inch gearcase

• OMC Sea Drive 1.8L V4 - 1987 onward with the 13-spline 4 1/4-inch gearcase

• OMC Model 400 2.3L - through 1991

• OMC Model 400 2.5L - 1978-1984

• OMC Model 400 3.0L - through 1989

• OMC Cobra 2.3L - 1988-1991

• OMC Cobra 2.5L - 1985-1987

• OMC Cobra 3.0L - 1985-1987

• Fitment excludes 25-inch E-TEC 90HP, 115HP and 130HP models equipped with the larger 15-spline gearcase

• HP Range: 40HP - 140HP outboards, plus compatible OMC Sea Drive and 2.3L-3.0L sterndrive applications

• Engine Type: Evinrude / Johnson two-stroke, E-TEC and applicable four-stroke outboard; OMC 400 / Cobra sterndrive

• Year Range: Approximately 1968 onward for matching 13-spline outboards; OMC sterndrive applications approximately 1978-1991

🔌 Function

The propeller converts engine torque into thrust. A 17-inch pitch generally favours cruising speed and lower engine RPM compared with a lower-pitch propeller, but the final choice must allow the engine to reach its specified wide-open-throttle RPM with the normal boat load.

Common signs of failure:

• Blades are bent, chipped or cracked

• Pressed rubber hub slips under acceleration

• Boat develops vibration or steering shake

• Engine cannot reach its recommended full-throttle RPM

• Cavitation, ventilation or poor planing develops after blade damage

📦 Condition

• Genuine used part

• Removed from running engine where applicable

• In good working condition unless otherwise stated
