Genuine Johnson Evinrude Stator-Wire Guide - Part Number: 0337478
A genuine used OMC / BRP guide for routing and protecting the stator wiring on selected Johnson and Evinrude outboard motors.
The small moulded guide positions the stator leads beneath the flywheel and around the ignition assembly, helping prevent the wires from contacting the rotating flywheel, timing components or sharp engine castings.
⚙️ Key Features
- Genuine used Johnson / Evinrude stator-wire guide
- Correct OEM part number 0337478
- Shortened reference 337478
- Protects and routes ignition-system wiring
- Factory shape for correct flywheel clearance
🚤 Compatibility
Commonly used on
- Johnson and Evinrude stator and ignition assemblies
- Outboards using routed stator leads beneath the flywheel
Typically suits
- Selected Johnson and Evinrude V4 and V6 two-stroke engines
- Known 150HP applications including late-1990s models
- Other model groups where the ignition-system diagram specifies 0337478
- Exact fitment must be confirmed by model number
- Engine Type: Johnson / Evinrude two-stroke outboard
- Year Range: Model dependent
🔌 Function
The guide retains the stator wires in the correct path and maintains safe clearance from the flywheel and moving timing components.
⚠️ Common Signs of Failure
- Guide is cracked or missing
- Stator wires rub against the flywheel
- Wiring insulation becomes chafed
- Ignition faults occur intermittently
- Leads are loose beneath the flywheel
- Mounting point is broken
- Harness contacts hot or sharp engine parts
🔄 Supersession & Cross Reference
OEM Supersession Chain
- 0337478 current original stator-wire-guide reference
OEM / Related Numbers
- 0337478
- 337478
- Related stator assembly
- Related timer base and power-pack wiring
- Related mounting screw or clamp according to model
- Related flywheel and ignition-cover components
Aftermarket / Verified Equivalents
- No aftermarket equivalent
📦 Condition
- Genuine used part
- Removed from running engine where applicable
- In good working condition unless otherwise stated
