• 0433352 Evinrude Johnson Pump AY Vapour | Genuine OEM BRP Outboard Part
1 1

0433352 Evinrude Johnson Pump AY Vapour | Genuine OEM BRP Outboard Part

0433352 Evinrude Johnson Pump AY Vapour | Genuine OEM BRP Outboard Part

$183.56 AUD
$183.56 AUD
Sale Sold out
Shipping calculated at checkout.

✓ Authorised Volvo Penta Dealer · Marine & auto specialists · Ships Australia-wide

🔧 Product Description

Genuine BRP Evinrude Johnson Vapour Pump Assembly - Part Number: 0433352

A genuine BRP vapour-pump assembly for selected 90HP-175HP Evinrude and Johnson two-stroke outboards.

The pump forms part of the engine's fuel and vapour-separator system. It helps circulate fuel and vapour through the fuel-supply assembly so the carburettors receive a stable liquid-fuel supply and vapour lock is reduced.

⚙️ Key Features

  • Genuine BRP OEM vapour pump
  • Correct OEM part number 0433352
  • Replaces earlier reference 0769296
  • Used in selected V4 and V6 fuel-system assemblies
  • Designed for marine petrol and oil-mix environments
  • Original BRP hose-port and mounting configuration

🚤 Compatibility

Commonly used on selected

  • 90HP
  • 100HP
  • 115HP
  • 150HP
  • 175HP Evinrude and Johnson outboards
  • Carburetted V4 and V6 fuel-system assemblies where 0433352 is specified

Important fitment note

  • Confirm the engine model and fuel-system diagram.
  • This component is not interchangeable with the main VRO, OMS or conventional fuel pump.
  • Hose routing, pulse connections and pump orientation must match the original system.

🔌 Function

The vapour pump helps move fuel and vapour through the vapour-separator or recirculation system.

Installation considerations

  • Replace hardened hoses and clamps
  • Confirm pulse-line integrity
  • Inspect the vapour separator and float valve
  • Check the primary fuel pump and primer bulb
  • Flush storage contamination before installation
  • Perform fuel-pressure and vacuum tests
  • Check carefully for fuel leakage before running

⚠️ Common Signs of Failure

  • Engine loses fuel supply at higher rpm
  • Hot restart is difficult
  • Fuel vapour accumulates in the system
  • Engine surges under load
  • Pump diaphragm leaks
  • Fuel is visible in the pulse line
  • Hose connections leak air or fuel
  • Pump does not respond to crankcase pulses

🔄 Supersession & Cross Reference

OEM Supersession Chain

  • 0769296
  • 769296
  • 0433352
  • 433352

OEM / Related Numbers

  • 0335385 - Related pump cover on applicable systems
  • 0340082 - Related fuel-system bracket on applicable engines
  • Associated vapour-separator, fuel hoses and clamps vary by model

Aftermarket / Verified Equivalents

  • No verified Sierra, GLM, Mallory, Recmar or EMP direct equivalent
  • Genuine new-old-stock and serviceable used OEM assemblies may be the only direct replacements
  • Generic pulse-operated fuel pumps must not be substituted without verified flow and port specifications

📦 Condition

  • Genuine BRP Evinrude Johnson OEM part
  • Brand new
  • Supplied in genuine or equivalent protective packaging
