🔧 Product Description

Genuine BRP Johnson Evinrude Starter Bus Bar and Insulating Tube Assembly - Part Number: 0583995

A genuine OMC / BRP high-current bus bar and insulating tube assembly used between the starter solenoid and starter motor on selected electric-start outboards.

The formed conductor carries starter current while the insulating sleeve reduces the risk of accidental contact or short-circuiting within the powerhead electrical compartment.

⚙️ Key Features

  • Genuine OMC / BRP starter-circuit component
  • Correct part number 0583995
  • Formed high-current copper bus bar
  • Supplied with insulating tubing where fitted
  • Connects the starter solenoid output to the starter terminal
  • Used across multiple Johnson and Evinrude engine families

🚤 Compatibility

Documented across selected

  • Johnson / Evinrude 25HP electric-start outboards
  • Johnson / Evinrude 35HP outboards
  • Johnson / Evinrude 90HP-115HP V4 outboards
  • Johnson / Evinrude 150HP-175HP V6 outboards
  • Approximately 1993-2005 electrical-system diagrams where 0583995 is specified
  • Electrical System: 12V DC
  • Engine Type: Johnson / Evinrude two-stroke outboard
  • Fitment Requirement: Confirm starter and solenoid terminal spacing

🔌 Function

The bus bar provides a low-resistance electrical path from the starter solenoid to the starter motor. When the solenoid closes, battery current flows through the bar to crank the engine.

⚠️ Common Signs of Failure

  • Starter cranks slowly despite a good battery
  • Bus bar becomes hot during cranking
  • Green corrosion forms around the conductor or terminals
  • Insulating tube is split or missing
  • Starter operation is intermittent because of loose terminal contact

🔄 Supersession & Cross Reference

OEM Supersession Chain

  • 0583995 current documented bus-bar-and-tubing reference

OEM / Related Numbers

  • 0583995
  • 583995
  • 0582708 related earlier starter solenoid
  • 0586180 related later starter solenoid
  • 0330112 related starter clamp
  • Related terminal nuts, washers and insulating boots

Aftermarket / Verified Equivalents

  • Kimpex: 827192 replacement bus bar
  • Specialist fabricated marine-grade bus bar matched to the original shape, conductor size and insulation
  • Used OEM 0583995 bus-bar assembly

📦 Condition

  • Genuine used part
  • Removed from running engine where applicable
  • In good working condition unless otherwise stated
  • Clean and tighten all high-current terminals during installation
