09403-17303 Suzuki DF60A Breather Hose Clamp | Genuine Used Part

09403-17303 Suzuki DF60A Breather Hose Clamp | Genuine Used Part

$5.00 AUD
$5.00 AUD
Sale Sold out
Shipping calculated at checkout.

Low stock: 1 left

🔧 Product Description

Genuine Suzuki DF40A-DF60A Breather Hose Clamp - Part Number: 09403-17303

A genuine Suzuki spring clamp used to secure the crankcase breather hose on selected DF40A, DF50A and DF60A four-stroke outboards.

The clamp maintains even pressure around the hose without requiring a screw adjustment. Later diagrams may list 09403-17312 as the updated clamp for the same service location.

⚙️ Key Features

  • Genuine Suzuki hose clamp
  • Original part number 09403-17303
  • Related updated reference 09403-17312
  • Sized for the documented crankcase breather hose
  • Spring-steel design maintains clamping force through heat cycles
  • Used on Suzuki 941cc inline-three outboards

🚤 Compatibility

Documented on

  • Suzuki DF40A
  • Suzuki DF50A
  • Suzuki DF50AV
  • Suzuki DF60A
  • Suzuki DF60AV
  • Selected tiller and remote-control variants using the 88L cylinder-head breather system
  • HP Range: 40HP - 60HP
  • Engine Type: Suzuki 941cc inline-three EFI four-stroke outboard
  • Fitment Requirement: Confirm hose diameter and production year

🔌 Function

The clamp seals the breather hose to its fitting so crankcase vapours are routed into the intake system without allowing oil mist or unmetered air to escape.

⚠️ Common Signs of Failure

  • Oil mist appears around the hose joint
  • Clamp has lost tension
  • Clamp is corroded or distorted
  • Hose slips off the fitting
  • Incorrect clamp size cuts into or fails to seal the hose

🔄 Supersession & Cross Reference

OEM Supersession Chain

  • 09403-17312 → Replaces 09403-17303 in selected later diagrams
  • 09403-17303 original breather-hose clamp reference

OEM / Related Numbers

  • 09403-17303
  • 09403-17312
  • 11174-88L00 related breather hose
  • 11174-88L01 later related breather hose
  • 09401-15414 related hose clip
  • 01550-06127 related mounting bolt

Aftermarket / Verified Equivalents

  • Marine-grade constant-tension spring clamp matched to the original hose outside diameter
  • Stainless worm-drive clamp may be used only where clearance and hose pressure permit
  • Genuine Suzuki 09403-17312 updated clamp

📦 Condition

  • Genuine used part
  • Removed from running engine where applicable
  • In good working condition unless otherwise stated
  • Confirm spring tension before reuse
