113604 Circuit Breaker Carling CLB 20A | Marine Electrical Part

🔧 Product Description

Circuit Breaker Carling CLB 20A - Part Number: 113604

A Carling CLB series thermal circuit breaker from the BEP range, rated at 20A.

BEP list the CLB series as single-pole push-to-reset thermal circuit breakers, rated at 250V AC with a 200 amp interrupt capacity, an operating range of -10 to 60°C, and approvals including UL, CUL, TUV, CE and ISO 8846. They are panel mounted, and BEP sell a boot as a separate accessory to seal the front.

Push-to-reset means there is no switch to leave in the wrong position: the button pops out when the breaker trips, and pushing it back in re-makes the circuit once the fault is cleared.

⚙️ Key Features

• 20A rating
• Single pole
• Push-to-reset thermal breaker
• Panel mount
• Rated 250V AC, 200A interrupt capacity
• UL, CUL, TUV, CE and ISO 8846 approved

📏 Specifications

• Current rating: 20A
• Voltage: 250V AC
• Interrupt capacity: 200A
• Type: single pole, push-to-reset thermal
• Operating range: -10 to 60°C

🔌 Function

Protects a circuit from overload and resets by hand, so a nuisance trip costs a button press rather than a spare fuse you do not have on board.

📦 Condition

• Brand new genuine product
• Supplied in original packaging
