130201 Stud | Genuine Volvo Penta Part

🔧 Product Description

A genuine Volvo Penta threaded mounting stud used in selected heavy-duty cooling-fan, fan-ring and viscous-fan-drive assemblies. The stud provides the fixed threaded mounting point for the fan or associated retaining hardware while maintaining the original spacing and clamping arrangement. Six studs are commonly used in the applicable fan assembly. Correct stud length and thread engagement are important because an incorrect fastener can reduce fan clearance, distort the hub or allow the fan attachment to loosen under vibration.

🚤 Compatibility

• Engine Family: TAD, D, TWD
• Year Range: Approximately 1990s - 2010s

Full model list at the end of this description.

⚙️ Key Features

• OEM Volvo Penta part number 130201
• Stud length: L=175 mm
• Net weight: 0.138 kg
• Fits D16 series and TAD/TWD industrial and marine diesel engines
• Supplied as a single stud
• Engine type: Volvo inline 6-cylinder turbo-diesel cooling system
• L=175mm (Volvo assembly listing)

🔌 Function

The stud screws permanently into a tapped hole in the engine and provides a fixed threaded projection onto which a mating component is located and clamped with a nut. This allows repeated removal and refitting of the component without wearing the threads in the parent casting.

⚠️ Common Signs of Failure

• Stretched or necked stud causing loss of clamping torque
• Damaged, galled or stripped threads preventing correct nut torque
• Corrosion or seizure making the nut impossible to remove without breaking the stud
• Stud snapped or sheared flush with the mounting face
• Repeated loosening of the fastened component or joint leakage at the mating face

🛠️ Service Notes

• Clean and chase the female thread before fitting so the stud can pull down square and to full depth
• Screw studs in with a proper stud installer or the double-nut method; gripping the plain shank with pliers or self-grips scores it and the nut will never seat or torque correctly afterwards
• Screw the stud home until it seats as the manual for your engine describes, and no further — a stud wound in hard to cure a slack thread will simply split the casting
• Renew studs that are stretched, necked, bent or corroded rather than reusing them; exhaust and manifold studs in particular are cheap next to the work of extracting a broken one
• Tighten the nuts to the torque figures and in the sequence given in the workshop manual for your engine, and where a stud passes into an oil or coolant space seal it as the manual specifies

🔄 Supersession & Cross Reference

OEM / Related Numbers

• 971095 related flange nut
• 3828964 related cooling fan

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D16C-A MG, D16C-A MH, D16C-B MH, D16C-C MH
• Volvo Penta TAD1640VE-B, TAD1640-42VE-C
• Volvo Penta TAD1642VE-B, TAD1642GE
• Volvo Penta TAD1650VE-B/51VE, TAD1650GE
• Volvo Penta TAD1240GE
• Volvo Penta TAD1241GE
• Volvo Penta TAD1242GE
• Volvo Penta TAD1351-53VE
• Volvo Penta TAD1371-75VE
• Volvo Penta TAD1380-82GE
• Volvo Penta TAD1381-85VE
• Volvo Penta TAD1641VE-B
• Volvo Penta TAD1651GE
• Volvo Penta TAD1660-62VE
• Volvo Penta TAD1662VE EU5
• Volvo Penta TAD1670-72VE
• Volvo Penta TWD1683VE
