1542061 Idler Gear | Genuine Volvo Penta Part

🔧 Product Description

A genuine Volvo Penta timing idler gear used across the 30-, 31-, 40-, 41-, 42-, 43-, 44- and KAD300 diesel families. The idler transmits crankshaft rotation to the camshaft, injection pump and associated gear-driven components while preserving the required timing relationship. The gear is installed with thrust washer 1542065 and related bushings and shafts. Volvo Penta lists it in product group 1800, function group 2153, including the KAD300-A timing-gear section.

🚤 Compatibility

• Engine Family: MD, TMD, TAMD, AD, AQAD, D, TD, AQD, KAMD, KAD
• HP Range: Approximately 90-300 HP
• Year Range: Approximately 1970s - 2000s

Full model list at the end of this description.

⚙️ Key Features

• OEM Volvo Penta part number 1542061
• System group: Engine
• Net weight: approximately 0.66 kg (0.665 kg)
• Fits MD30, MD31, MD40, TD, TMD, TAMD, AD, AQAD, AQD, KAD and KAMD 30-44 series marine diesel engines
• Single idler gear, supplied individually
• Engine type: Volvo Penta 4- and 6-cylinder marine diesel timing-gear drive

🔌 Function

The idler gear meshes between two other gears in the engine's gear train to transmit drive while setting the correct direction of rotation and centre distance. It keeps driven components such as the camshaft or auxiliary drives correctly timed to the crankshaft.

⚠️ Common Signs of Failure

• Whining, howling or rattling noise from the timing gear area that changes with engine speed
• Visible tooth wear, chipping, pitting or spalling on the gear teeth
• Excessive gear backlash or play when checked against specification
• Worn idler bearing or bushing allowing gear wobble and misalignment
• Metal particles or gear debris found in the oil or on the sump magnet

🛠️ Service Notes

• Inspect the gear teeth, the bearing or bushing and the shaft or hub it runs on together — a new gear on a worn shaft will be noisy and short-lived
• Check the mating gears at the same time; a chipped or pitted tooth on either side will damage the new idler
• Where the gear forms part of a timed drive, set it up to the timing marks and the procedure in the workshop manual for your engine and confirm timing before turning the engine over
• Measure backlash and endfloat by the method in the manual rather than judging them by feel, and fit any thrust washer or plate in its original order and direction
• Oil the bearing surfaces and teeth on assembly and turn the drive over by hand to check it runs free before the covers go back on

🔄 Supersession & Cross Reference

OEM / Related Numbers

• 1542034 related camshaft gear
• 1542065 related thrust washer
• 1542067 related camshaft bushing

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta TAMD31L-A, TAMD31M-A, TAMD31P, TAMD31P-A, TAMD31S, TAMD31A, TAMD31B, TAMD31D
• Volvo Penta AD31, AD31B, AD31D-A, AD31L-A, AD31P-A, AD31XD
• Volvo Penta AD41B, AD41D, AD41L-A, AD41P-A, AD41A, AD41BJ
• Volvo Penta TAMD41B, TAMD41D, TAMD41H-A, TAMD41H-B, TAMD41P-A, TAMD41A
• Volvo Penta TMD31A, TMD31B, TMD31D, TMD31L-A
• Volvo Penta TMD41A, TMD41B, TMD41D, TMD41L-A
• Volvo Penta D41B, D41D, D41L-A
• Volvo Penta KAD42A, KAD42B, KAD42P-A
• Volvo Penta KAD44P, KAD44P-B, KAD44P-C
• Volvo Penta KAMD42A, KAMD42B, KAMD42P-A
• Volvo Penta KAMD43P, KAMD43P-A, KAMD43P-B
• Volvo Penta KAMD44P-B, KAMD44P-C, KAMD44P-A
• Volvo Penta TMD40A, TMD40B, TMD40C
• Volvo Penta AQAD40B, AQAD40A
• Volvo Penta TAMD40A, TAMD40B
• Volvo Penta TAMD42WJ-A, TAMD42B
• Volvo Penta AQAD30A
• Volvo Penta AQD40A
• Volvo Penta KAD300-A
• Volvo Penta KAD32P
• Volvo Penta KAD43P-A
• Volvo Penta KAMD300-A
• Volvo Penta MD30A
• Volvo Penta MD31A
• Volvo Penta MD40A
• Volvo Penta TAMD30A
• Volvo Penta TD30A
• Volvo Penta TD31ACE
• Volvo Penta TD40A
• Volvo Penta TMD30A
