15710-65D00 Aftermarket Suzuki Injector 90-115 Hp 4-Cylinder Engines | Sawley’s Select Marine Parts

🔧 Product Description

Sawley's Select Marine Parts Aftermarket Suzuki Fuel Injector - Part Number: 15710-65D00

A new aftermarket replacement fuel injector for selected Suzuki DF four-stroke outboards. This injector replaces Suzuki 15710-65D00 and is commonly used on DF90, DF100, DF115 and DF140 four-cylinder EFI fuel-injection systems where the original injector number matches.

⚙️ Key Features

• Sawley's Select Marine Parts aftermarket replacement injector

• Replaces Suzuki OEM part number 15710-65D00

• Used on selected Suzuki 4-cylinder four-stroke EFI systems

• Also cross-references with Johnson / Evinrude 5033708 in Suzuki-built applications

• Suits EFI fuel rail applications using the 15710-65D00 injector style

🔄 Supersession & Cross Reference

OEM Supersession Chain:

• 15710-65D00 Suzuki fuel injector reference

• 15710-65D00-0000 Suzuki full OEM injector reference

• 5033708 Johnson / Evinrude cross-reference for Suzuki-built applications

OEM / Related Numbers:

• 15710-65D00

• 1571065D00

• 15710-65D00-0000

• 5033708

• Fuel injector

• Injector assembly

• EFI injector

• 4-cylinder fuel injector

Aftermarket / Verified Equivalents:

• WSM: 610-314

• CDH210

• INP771

• 4G1153

• MP4115

• FJ411

• M02771X4

🚤 Compatibility

Commonly used on:

• Suzuki DF90 / DF100 / DF115 / DF140 four-cylinder EFI fuel systems

• Suzuki-built Johnson / Evinrude 90HP / 115HP / 140HP four-stroke EFI applications

Typically suits:

• Engine models:

• Suzuki DF90 - 2001-2008

• Suzuki DF90TL - 2001-2007

• Suzuki DF100 - 2009-2011

• Suzuki DF115 - 2001-2011

• Suzuki DF115TL - 2001-2007

• Suzuki DF140 - 2002-2011

• Suzuki DF140T - 2002-2010

• Suzuki DF140Z - 2002-2010

• Johnson / Evinrude 90HP 4-cylinder four-stroke - 2003-2006

• Johnson / Evinrude 115HP 4-cylinder four-stroke - 2003-2006

• Johnson / Evinrude 140HP 4-cylinder four-stroke - 2003-2006

• HP Range: 90HP - 140HP

• Engine Type: Suzuki four-stroke EFI outboard fuel system

• Year Range: approximately 2001 - 2011 depending on model

• Serial / VIN Note: Confirmed Suzuki fuel-injector diagram examples include DF140TXK2 beginning VIN 14001F-251001, DF140TLK3 beginning VIN 14001F-371001, DF140TXZK4 beginning VIN 14001Z-421001, DF140TXK5 beginning VIN 14001F-510001, DF140TXZK5 beginning VIN 14001Z-510001, DF115TXK9 beginning VIN 11501F-980001 and DF100TXK10 beginning VIN 10002F-010001. Match by exact Suzuki model code, serial / VIN, fuel rail layout and original injector number before installation.

🔌 Function

The fuel injector meters and sprays fuel into the intake system so the ECU can control fuel delivery for starting, idle, acceleration and high-RPM operation.

Common signs of failure:

• Hard starting

• Rough idle

• Misfire on one cylinder

• Hesitation or flat spot under acceleration

• Poor fuel economy

• Fuel smell from leaking injector

• Engine runs better when injector is cleaned or replaced

• Cylinder fault follows the injector during substitution testing

📦 Condition

• Aftermarket replacement part

• Brand new

• Supplied in original or equivalent packaging
