1677359 Shim | Genuine Volvo Penta Part

🔧 Product Description

This genuine Volvo Penta shim is a calibrated valve-clearance shim used in the exhaust-valve clearance adjustment. It is manufactured to the original Volvo dimensional, material and interface requirements so the serviced assembly retains its designed alignment, sealing, load capacity and operating reliability. Calibrated shim thickness: 3.50 mm. In service, it sets exhaust-valve clearance by providing a calibrated 3.50 mm thickness at the designated valve-train position. Selection must be confirmed by OEM part number 1677359, the exact engine/product model, serial number and the installed assembly configuration.

🚤 Compatibility

Typically suits:

• Volvo Penta TAD1353GE
• Volvo Penta TAD1350GE
• Volvo Penta TAD1351GE
• Volvo Penta TAD1352GE
• Volvo Penta TAD1354GE
• Volvo Penta TAD1355GE
• Volvo Penta TAD1170-72VE
• Volvo Penta TAD1140-42VE

• Engine Family: TAD

⚙️ Key Features

• OEM Volvo Penta part number 1677359
• Thickness: 3.50 mm
• System group: Engine
• Net weight: 0.027 kg
• Fits TAD1350-1355GE, TAD1140-42VE and TAD1170-72VE industrial and genset diesel engines
• Thickness-specific component - sibling shims share the same name in other sizes
• TH=3.50mm (Volvo assembly listing)
• 6 used per assembly

🔌 Function

The shim acts as a precision spacer that sets or adjusts clearance, alignment or preload between two mating engine components. Selecting the correct thickness ensures assembled dimensions fall within the specified tolerance.

⚠️ Common Signs of Failure

• Measured clearance or endplay outside the specified tolerance during assembly
• Visible wear, scoring or pitting on the shim faces
• Deformation, dishing or cracking from overload or improper torque
• Fretting marks or discolouration indicating movement between mating surfaces
• Abnormal noise or vibration from the assembly caused by incorrect stack height

🛠️ Service Notes

• Shims are supplied in graded thicknesses and exist to bring a setting into specification, so measure with a micrometer and select the thickness the setting procedure for your engine calls for rather than matching one by eye
• Note which shim came from which position on removal and keep them identified — once an assembly has bedded in, shims are not interchangeable between positions
• Check both faces are clean, flat and free of burrs, corrosion and old sealant before fitting; dirt trapped under a shim shifts the setting as surely as the wrong thickness does
• Discard any shim that is dished, cracked, pitted or fretted rather than reusing it, and make sure no old shim has been left behind in the recess
• Recheck the clearance or setting after the assembly is tightened down, because clamping load can change the measurement you took loose

🔄 Supersession & Cross Reference

Aftermarket / Verified Equivalents

• Vaden Original: 1300 05 031

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
