181302 Cup | Genuine Volvo Penta Part

🔧 Product Description

This genuine Volvo Penta cup is a precision rolling-element or raceway component used in the TAD11 lower-gear and legacy AQ145A tapered-bearing assembly. It is manufactured to the original Volvo dimensional, material and interface requirements so the serviced assembly retains its designed alignment, sealing, load capacity and operating reliability. In service, it provides the hardened outer raceway for the matching tapered roller bearing cone/inner-ring assembly. Selection must be confirmed by OEM part number 181302, the exact engine/product model, serial number and installed configuration.

🚤 Compatibility

• Engine Family: MD, TMD, AQ, AD, AQAD, D, BB, TAMD, MS, DP, SP, DPX, TAD, AQD

Full model list at the end of this description.

⚙️ Key Features

• OEM Volvo Penta part number 181302
• Bearing cup (outer race) for a tapered roller bearing
• Supersedes previous part number 3852119
• Net weight 0.132 kg
• Fits MD, TMD, AQ, AD, AQAD and D series engines and drives

🔌 Function

Provides the hardened outer raceway for the matching tapered roller bearing cone/inner-ring assembly. Measure shaft and housing fits, renew contaminated lubricant and related seals, and install using force only through the race being fitted. Set preload or end float to the applicable Volvo Penta specification.

⚠️ Common Signs of Failure

• Rumbling or grinding from the bearing housing
• Pitting, scoring or flaking of the race surface
• Blue or brown heat discolouration
• Notchy or rough feel when the shaft is turned
• Metallic particles in the lubricant

🛠️ Service Notes

• Renew the cup and its matching cone or roller assembly together as a set; a new roller set run in a used cup will not last
• Clean the housing bore and check it for wear, scoring and corrosion, and remove any burr so the cup can seat properly
• Drive or press the cup in square, bearing only on its back face with a tool that matches its diameter, until it is hard against its shoulder — a cup that is not fully home throws the whole bearing setting out
• Never strike a bearing race directly with a steel hammer and never press through the rollers
• Lubricate with the specified oil or grease and set the bearing preload or end float by the method and figures given in the workshop manual for your unit

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 181302 → Supersedes 3852119

OEM / Related Numbers

• 181301 inner ring
• 17463337 flywheel housing
• 17487259 dual-PTO flywheel housing

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta 2003, 2003R, 2003R SOLAS, 120S, 120S-B, 740B, 500A, 501A, 501B, 570A, 572A, 740A, 430A, 430B, 431A, 431B, 432A, 434A, 2003TB, 2003TB SOLAS, 280B, 290A, 290DP, 120SC, 120S-D, 120S-E, 2001AG, 2001B, 2001BG, 2001D, 2003D, 2003T, 2003TR, 2002AG, 2002B, 2002BG, 2002D, 2003B, 2003B SOLAS, 2003 SOLAS, 2001, 570, 500B, 500, 2002, 430, 2001R
• Volvo Penta DP-C, DP-C1, DP-D, DP-D1, DP-A, DP-A1, DP-A2, DP-B, DP-B1
• Volvo Penta MS2B-A, MS2B-L, MS2L-E, MS2B, MS2V, MS2A-D, MS2A-E
• Volvo Penta AD31, AD31B, AD31D, AD31D-A, AD31XD
• Volvo Penta AD41P-B, AD41B, AD41, AD41A, AD41BJ
• Volvo Penta SP-C, SP-A2, SP-C1, SP-A, SP-A1
• Volvo Penta BB225A, BB225AV, BB225B, BB225C
• Volvo Penta TAMD31M, TAMD31A, TAMD31B, TAMD31D
• Volvo Penta AQ225D, AQ225E, AQ225F
• Volvo Penta BB260AV, BB260B, BB260C
• Volvo Penta MD5A, MD5B, MD5C
• Volvo Penta TAMD41B, TAMD41M-A, TAMD41A
• Volvo Penta TMD31A, TMD31B, TMD31D
• Volvo Penta TMD40A, TMD40B, TMD40C
• Volvo Penta AQ260A, AQ260B
• Volvo Penta AQAD40B, AQAD40A
• Volvo Penta D41, D41B
• Volvo Penta MD11C, MD11D
• Volvo Penta MD17C, MD17D
• Volvo Penta MD2010-C, MD2010-D
• Volvo Penta MD2020-C, MD2020-D
• Volvo Penta MD2030-C, MD2030-D
• Volvo Penta MD2040-C, MD2040-D
• Volvo Penta MD22, MD22A
• Volvo Penta MD6A, MD6B
• Volvo Penta MD7B, MD7A
• Volvo Penta MS3B, MS3C
• Volvo Penta MS4B, MS4A
• Volvo Penta MS5A, MS5B
• Volvo Penta TAMD40A, TAMD40B
• Volvo Penta TMD41A, TMD41B
• Volvo Penta AD40B
• Volvo Penta AQ145A
• Volvo Penta AQD21B
• Volvo Penta AQD40A
• Volvo Penta BB145A
• Volvo Penta BB231A
• Volvo Penta BB261A
• Volvo Penta BB740A
• Volvo Penta D2002AG
• Volvo Penta D2003AG
• Volvo Penta DPX
• Volvo Penta MD21B
• Volvo Penta MD30A
• Volvo Penta MD31A
• Volvo Penta MD40A
• Volvo Penta MD67C
• Volvo Penta TAD1170-72VE
• Volvo Penta TAMD30A
• Volvo Penta TMD22A
• Volvo Penta TMD30A
