184659 Roller Bearing | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta Roller Bearing - Part Number: 184659

This genuine Volvo Penta roller bearing is a precision rolling-element or raceway component used in the IPS lower-gear tapered-roller bearing position. It is manufactured to the original Volvo dimensional, material and interface requirements so the serviced assembly retains its designed alignment, sealing, load capacity and operating reliability. Tapered roller-bearing dimensions documented as 55 mm bore × 100 mm outside diameter. SKF-manufactured OEM bearing documented for Volvo Penta transmission service. In service, it supports the IPS lower-gear shaft under combined radial and thrust loading and maintains bevel-gear alignment. Selection must be confirmed by OEM part number 184659, the exact engine/product model, serial number and installed configuration.

⚙️ Key Features

• Genuine Volvo Penta OEM roller bearing

• OEM part number 184659

• Documented application: IPS lower-gear tapered-roller bearing position

• Validated family: Volvo Penta IPS-A and IPS lower gear

• Tapered roller-bearing dimensions documented as 55 mm bore × 100 mm outside diameter

• SKF-manufactured OEM bearing documented for Volvo Penta transmission service

• Primary function: Supports the IPS lower-gear shaft under combined radial and thrust loading and maintains bevel-gear alignment.

• Measure shaft and housing fits, renew contaminated lubricant and related seals, and install using force only through the race being fitted. Set preload or end float to the applicable Volvo Penta specification.

🔄 Supersession & Cross Reference

OEM Supersession Chain:

• 184659 (current/original OEM service reference)

OEM / Related Numbers:

• 184659

• IPS-A lower gear unit

Aftermarket / Verified Equivalents:

• No aftermarket equivalent

🚤 Compatibility

Commonly used on:

• IPS lower-gear tapered-roller bearing position

Typically suits:

• Engine / product models:

• IPS-A

• IPS lower-gear assemblies specifying bearing 184659

• Engine / Application Family: Volvo Penta IPS-A and IPS lower gear

• Serial / Configuration Note: Confirm part number 184659 against the exact drive, transmission or engine serial number, bearing location and installed shaft/housing arrangement; adjacent gear ratios and production variants may use different race dimensions or preload components.

🔌 Function

Supports the IPS lower-gear shaft under combined radial and thrust loading and maintains bevel-gear alignment. Measure shaft and housing fits, renew contaminated lubricant and related seals, and install using force only through the race being fitted. Set preload or end float to the applicable Volvo Penta specification.

Common signs of failure:

• Rumbling, growling, clicking or cyclic rotational noise

• Excessive radial or axial play measured at the supported shaft

• Localised heat, lubricant discolouration or burnt odour at the bearing position

• Pitting, brinelling, flaking, corrosion or scoring on rollers and raceways

• Vibration, shaft run-out or repeated seal/gear wear caused by loss of alignment

📦 Condition

• Genuine Volvo Penta part

• Brand new

• Supplied in original or equivalent packaging
