20712545 Gasket | Genuine Volvo Penta Part

🔧 Product Description

A genuine moulded side-cover/oil-cooler gasket for Volvo Penta D12 engines. It seals the long oil-cooler or cylinder-block side-cover interface and prevents oil/coolant leakage between the cover, cooler and block.

🚤 Compatibility

• Engine Family: D, TWD, TAD

Full model list at the end of this description.

⚙️ Key Features

• Moulded profile matched to the D12 oil-cooler/side-cover joint
• Oil- and heat-resistant elastomer construction
• Long-form gasket follows the cooler and block passage layout
• Provides controlled compression around oil and coolant galleries
• Mating surfaces must be clean and flat before installation
• Single-use replacement is recommended whenever the side cover is removed

🔌 Function

Seals the D12 oil-cooler/side-cover joint against engine-oil and coolant leakage.

⚠️ Common Signs of Failure

• Oil or coolant leaks along the side cover
• Oil and coolant begin to cross-contaminate
• The gasket is swollen, split or permanently compressed
• Residue or staining appears around the cooler joint
• Replacement is required whenever the side cover is removed

🛠️ Service Notes

• Fit a new gasket every time the joint is disturbed — a gasket takes a permanent set once it has been torqued and will not seal reliably a second time
• Scrape both faces back to clean bare metal, keeping the blade at a shallow angle so it lifts the old material without gouging the surface, and use a plastic scraper on aluminium castings
• Check the faces for flatness, cracks and corrosion pitting, and make sure no old gasket, carbon or hardened sealant is left in the corners or around the bolt holes
• Fit the gasket dry unless the workshop manual for your engine calls for a sealant, and then only the type it specifies — surplus sealant squeezes out into oil, coolant and fuel passages
• Draw the fasteners down progressively in the sequence and to the torque given in the manual for your engine, and recheck after the first heat cycle where the manual asks for it

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 20712545 → Supersedes 1677656

OEM / Related Numbers

• 1677656 earlier number superseded by this part

Other-Brand OEM Numbers

• ELRING: 355.980
• Victor Reinz: 70-24875-10
• Victor Reinz: 70-36352-00

Aftermarket / Verified Equivalents

• AJUSA: 01152500
• TRUCKTEC Automotive: 03.10.015
• FEBI Bilstein: 40885
• DT Spare Parts: 2.11426
• LEMA: 26225.10
• AUGER: 87202
• MEC-DIESEL: 961529
• SLP: EPL-545
• ATP Diesel: GS-56
• LEMA: 26225.1
• Sampa: 035.327
• SLP: EPL-656

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D12C-A MP, D12D-A MG, D12D-A MH, D12D-A MP, D12D-B MH, D12D-B MP, D12D-C MH, D12D-C MP, D12D-D MP, D12D-E MG, D12D-E MH, D12D-E MP, D12D-F MP, D12D-G MH, D12D-G MP, D12D-H MP
• Volvo Penta TAD1241GE, TAD1241VE, TAD1241-42VE
• Volvo Penta TAD1242GE, TAD1242VE
• Volvo Penta TAD1250VE, TAD1250-52VE
• Volvo Penta TAD1240GE
• Volvo Penta TAD1251VE
• Volvo Penta TAD1252VE
• Volvo Penta TWD1240VE
