20938951 Flange Nut | Genuine Volvo Penta Part

🔧 Product Description

OEM fastening or load-distribution component used in the common-rail low-pressure fuel supply and return assembly. It restores the specified thread, strength, length and clamping geometry required by the original assembly.

🚤 Compatibility

Typically suits:

• Volvo Penta TAD550GE
• Volvo Penta TAD551GE
• Volvo Penta TAD560VE
• Volvo Penta TAD561VE

• Engine Family: TAD
• HP Range: Approximately 320 HP
• Year Range: Approximately 2000s-2010s

⚙️ Key Features

• Flange nut, 0.007 kg
• Listed for 4 TAD-series applications
• Slightly larger than flange nut 20933396 at 0.005 kg, so order by part number rather than by eye

🔌 Function

Clamps a stud or bolt in the low-pressure fuel supply and return assembly, spreading its load through the integral flange.

⚠️ Common Signs of Failure

• Fuel joint or bracket working loose
• Nut turns without gaining torque
• Flange face scored or corroded
• Thread damaged so the nut binds part way down

🛠️ Service Notes

• Check the flange seats flat on a clean, undamaged face; a flange nut is designed to spread its load without a separate washer, so do not add one unless the workshop manual for your engine shows it
• Clean the thread and inspect it for damage, corrosion and stretch before reuse of the stud or bolt, and renew the nut if it is a prevailing-torque or all-metal locking type that has already been run down once
• Tighten to the figure and sequence given in the manual for your engine, in stages where several nuts share a joint, so the component is pulled down evenly
• Use the correct size ring spanner or socket rather than an open-ended spanner — the flange leaves little room and a slipping spanner rounds the hexagon
• Recheck the joint after the first period of running, especially on exhaust, manifold and mounting joints that heat cycle

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
