21106517 Hose | Genuine Volvo Penta Part

🔧 Product Description

Brand-new genuine Volvo Penta moulded hose forming the upper exhaust-thermostat connection on 5.0-litre catalyst engines. It connects the thermostat-housing circuit to the remaining exhaust cooling hoses and is shaped to clear the intake and exhaust hardware.

🚤 Compatibility

• Engine Family: V
• HP Range: 225-320 HP

Full model list at the end of this description.

⚙️ Key Features

• Upper hose in the 5.0GXiCE exhaust-thermostat circuit
• Indexed moulded shape prevents routing errors
• Compatible with the original hose clamps and thermostat fittings
• Rated for warm pressurised coolant
• Hose only; clamps and adjoining hoses are separate
• Engine type: Volvo Penta 5.0-litre V8 catalyst marine gasoline engine

🔌 Function

Transfers coolant between the exhaust thermostat and the engine/exhaust cooling circuit while preserving the factory flow balance.

⚠️ Common Signs of Failure

• Coolant seepage around a clamp
• Hose hardening from exhaust heat
• One exhaust bank running hotter than the other
• Hose collapse during cool-down

🛠️ Service Notes

• Fit hoses only to clean, sound spigots — take off old rubber, scale and corrosion, and renew the spigot or pipe if it is pitted, because no clamp will seal a rough sealing face
• Push the hose fully home so the clamp sits behind the bead or barb rather than over the end of the spigot, and fit new clamps whenever a hose is renewed
• Let the hose follow its natural bend with no kinks and no tension on either connection, clear of hot surfaces and moving parts, with chafe protection wherever it passes a bracket, edge or bulkhead
• Use the correct grade of hose for the duty, and clamp to the standard the installation demands — twin clamps are normal practice on seawater and fuel connections below the waterline
• Refill, vent and run the engine, then check every joint hot and cold and recheck the clamps after the first running period as the hose beds down

🔄 Supersession & Cross Reference

OEM / Related Numbers

• Companion hose 21107967
• Thermostat housings 40005486 and 40005487

Other-Brand OEM Numbers

• VOE21106517

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta 5.7GXiC-320-R, 5.7GXiCE-320-R, 5.7GXiC-J, 5.7GXiCE-J, 5.7GXiCE-M, 5.7GXiC-P, 5.7GXiCE-P, 5.7GiCE-300-M, 5.7GiC-300-J, 5.7GiCE-300-J, 5.7GiC-300-P, 5.7GiCE-300-P, 5.7GiC-300-R, 5.7GiCE-300-R, 5.0GiC-225-S, 5.0GiCE-225-S, 5.0GiC-J, 5.0GXiCE-J, 5.0GXiCE-M, 5.0GXiC-P, 5.0GXiCE-P, 5.0GXiC-270-R, 5.0GXiCE-270-R, 5.0GXiC-J
• Volvo Penta V8-270-C-B, V8-270-CE-B, V8-300-C-A, V8-300-CE-A, V8-300-C-B, V8-320-C-B, V8-320-CE-B, V8-300-CE-B, V8-320-C-A, V8-320-CE-A, V8-225-C-A, V8-225-CE-A, V8-225-C-B, V8-225-CE-B, V8-270-C-A, V8-270-CE-A
