21123875 Sensor | Genuine Volvo Penta Part

🔧 Product Description

Genuine rotational-speed sensor used in the Volvo Penta DPI-A transmission and gear-housing system. It detects shaft or gear speed and sends the RPM signal to the electronic control system for monitoring and control.

🚤 Compatibility

• Engine Family: D, IPS, DPI
• HP Range: 150-440 HP

Full model list at the end of this description.

⚙️ Key Features

• Exact DPI-A drive application
• Measures transmission or drive rotational speed
• Factory electrical connector and sensing specification
• Supports EVC monitoring and control
• Installed in the gear-housing sensor assembly

🔌 Function

The sensor converts rotating gear or shaft movement into an electrical RPM signal for the transmission or EVC controller.

⚠️ Common Signs of Failure

• Missing or erratic drive RPM reading
• Transmission or EVC warning
• Shift-control fault
• Intermittent signal when warm
• Signal changes when wiring is moved

🛠️ Service Notes

• Note how the sensor sits and how its lead is routed before removing it, and support the harness so refitting does not leave the cable strained or rubbing
• Turn the sensor with a spanner on its hex only — never lever or twist it by the connector body or the wiring, which breaks the internal joint even when the sensor looks undamaged
• Renew the O-ring or sealing washer where one is fitted, and do not add thread sealant unless the manual for your engine specifies it; sealant on the threads can break the earth path of a sensor that earths through its body
• Tighten to the figure in the workshop manual for your engine — overtightening distorts the housing and shifts or destroys the sensing element
• Make sure the connector is clean, dry and fully latched home and check the pins for corrosion and spread — a poor connector accounts for a great many faults blamed on the sensor — then run the engine and confirm the reading or warning lamp behaves sensibly before returning the boat to service

🔄 Supersession & Cross Reference

Other-Brand OEM Numbers

• Valeo: 366138
• Magneti Marelli: 064847217010
• Bosch: 0 232 103 063
• Lucas: LCS076

Aftermarket / Verified Equivalents

• Meat & Doria: 87771
• Meat & Doria: 87771E
• ESEN SKV: 17SKV229
• Meyle: 514 810 0000
• Maxgear: 24-0256
• SIDAT: 83.3075A2
• Vemo: V95-72-0015
• EPS: 1.953.607

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D13C2-B MP, D13C2-A MP, D13C4-A MP, D13B-L MP, D13B-G MP, D13B-K MP, D13B-C MP, D13C6-A MP, D13C4-B MP, D13C5-B MP, D13C5-A MP, D13C7-B MP, D13C8-B MP
• Volvo Penta D11C2-A MP, D11C4-A MP, D11B2-A MP, D11A-D MP, D11A-E MP
• Volvo Penta D4-150A-G, D4-230A-G, D4-270A-G, D4-320A-G, D4-300A-G
• Volvo Penta D6-300A-G, D6-340A-G, D6-380A-G, D6-400A-G, D6-440A-G
• Volvo Penta IPS3-C, IPS3-A
• Volvo Penta IPS30-E, IPS30-D
• Volvo Penta D8A4-A MP
• Volvo Penta DPI-A
• Volvo Penta IPS2-B
• Volvo Penta IPS20-E
