21133055 Dipstick | Genuine Volvo Penta Part

🔧 Product Description

A calibrated fluid-level dipstick for the d5/d7-series inline diesel engine installation. The overall length, stop position and MIN/MAX marks are matched to the specified pan, tank or reservoir geometry.

🚤 Compatibility

Typically suits:

• Volvo Penta 8.1IPSCE-JF
• Volvo Penta 8.1IPSCE-MF
• Volvo Penta 8.1IPSCE-P
• Volvo Penta 8.1IPSCE-Q
• Volvo Penta 8.1IPSE-JF

⚙️ Key Features

• Calibrated length and stop position
• Clearly defined MIN/MAX range
• Handle and seal suit the original tube
• Must be paired with the correct sump or tank
• Engine level and shutdown time affect the reading
• Engine type: D5/D7-series inline diesel engine

🔌 Function

Provides a direct visual indication of the operating-fluid level at the calibrated measuring position.

⚠️ Common Signs of Failure

• Oil leakage at the joint or fitting
• Incorrect or unstable level indication
• Restricted flow or oil backup
• Cracking, chafe or heat damage
• Abnormal oil pressure, smoke or component wear

🛠️ Service Notes

• Wipe the dipstick clean before every check, and take the reading with the boat at its normal attitude and following the procedure in the operator's manual for your engine
• Push it fully home to its stop so the marks read correctly, and make sure the seal or grommet at the top seats — one not pushed home lets oil mist out and dirt in
• Fit only the dipstick listed for your engine, as length and mark position are matched to the sump; a substitute will give a false level
• Renew one that is bent, kinked or has worn or unreadable marks, and check the tube is clear and secure in its bracket

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
