21143184 Control Unit | Genuine Volvo Penta Part

🔧 Product Description

Brand-new genuine Volvo Penta EVC helm/control unit for D12D-B MP marine installations. The unit processes helm commands and communicates them over the EVC network to the engine and transmission controls. It is supplied unprogrammed and requires the correct Volvo Penta software/configuration before operation.

🚤 Compatibility

• Engine Family: D
• HP Range: 180-370 HP

Full model list at the end of this description.

⚙️ Key Features

• EVC electronic helm control unit
• Supports engine and transmission command communication
• Marine-sealed connectors and network electronics
• Requires VODIA/warehouse programming to the vessel configuration
• Control unit only; harness, panel and programming service are separate
• Engine type: Volvo Penta D12 electronically controlled marine diesel

🔌 Function

Receives helm inputs, validates control commands and exchanges engine/transmission data through the EVC network.

⚠️ Common Signs of Failure

• No EVC communication
• Engine starts but throttle or shift is unavailable
• Intermittent helm alarms
• Configuration or node-identification faults
• Water-damaged or corroded connector pins

🛠️ Service Notes

• A replacement control unit normally has to be loaded with the software and parameter set for your engine and installation before it will run — that is authorised-dealer work with Volvo Penta's own diagnostic tool, so plan the job around it rather than around the fitting time
• Isolate the batteries at the main switches and leave the system dead before disconnecting or connecting anything; back-feeding a live bus through a half-mated connector is a common way to destroy a new unit
• Treat the unit as static-sensitive and mechanically delicate: handle it by its housing, leave it in its packaging until it is going on, and never weld on the boat with control units connected
• Mate connectors clean and dry and push them fully home until the lock engages, then refit the harness clips and any shielding so the loom is not left hanging on the plugs
• Mount it in its own bracket and original orientation so the cable entries face as designed and water runs away from the connectors rather than into them

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 21143184 → Supersedes 3840320 → Supersedes 3589080

OEM / Related Numbers

• 3840320 earlier number superseded by this part
• 3589080 earlier number superseded by this part
• Software reference 3586261 / 3586259
• Alternate HCU 3840321 with software 3586267 / 3586266

Other-Brand OEM Numbers

• VOE21143184

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D6-350A-A, D6-350A-B, D6-370D-B, D6-370D-A, D6-310I-B, D6-280I-B, D6-280I-A, D6-310I-A, D6-310D-B, D6-370I-A, D6-370I-B, D6-310A-B, D6-310A-A, D6-280A-A, D6-280A-B, D6-370A-B
• Volvo Penta D4-260A-B, D4-260A-A, D4-260D-B, D4-260I-A, D4-260I-B, D4-210A-A, D4-210A-B, D4-225A-B, D4-210I-A, D4-210I-B, D4-180I-B, D4-225I-B
• Volvo Penta D9A2J, D9A2G, D9A2D, D9A2B, D9A2F, D9A2K, D9A2H, D9A2A, D9A2C, D9A2E
• Volvo Penta D12D-B MP
• Volvo Penta D16C-A MH
