21230282 Lock Ring | Genuine Volvo Penta Part

🔧 Product Description

A hardened retaining ring installed at each end of the piston pin on selected Volvo Penta D5, D8 and TAD engines. Two rings are normally required per piston to prevent lateral movement of the pin.

🚤 Compatibility

• Engine Family: TAD, D, TADH

Full model list at the end of this description.

⚙️ Key Features

• Two normally required per piston
• Hardened spring-steel construction
• Replace whenever removed during engine overhaul
• Direct replacement where part number 21230282 is specified
• Engine type: Four- or six-cylinder turbocharged diesel

🔌 Function

Retains the piston pin within the piston and prevents the pin from contacting the cylinder liner.

⚠️ Common Signs of Failure

• Scoring along the cylinder liner
• Piston-pin movement or knocking
• Broken ring fragments in the sump
• Damaged piston retaining groove
• Severe piston and liner damage

🛠️ Service Notes

• Always fit a new lock ring rather than reusing one; once it has been spread to fit it has lost some of its grip
• Use the correct tool and open the ring only as far as it needs to go — a ring that has been over-spread or nipped in a vice will not hold
• Check that the groove is clean and undamaged and that the ring is seated fully round its whole circumference before the assembly is loaded
• Fit the ring the right way round where one face is chamfered or dished, with the square-cornered face against the load
• Reject any ring showing a twist, a bright rubbed patch or a nick, and never grind or file one to fit

🔄 Supersession & Cross Reference

OEM / Related Numbers

• 22960905 - D8 piston pin
• 22203232 - D5 or TAD piston pin
• 22720412 and 22222394 - piston-ring kits
• 23228685 and 23228687 - cylinder-liner kits

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D8A2-A MP, D8A5-A MH, D8A6-A MH, D8A5-A MG, D8A6-A MG, D8A4-A MP, D8A1-A MP, D8A3-A MP
• Volvo Penta TAD840GE, TAD840-43VE, TAD840GE-B
• Volvo Penta TAD570-72VE, TAD570-71VE-B
• Volvo Penta TAD880-82GE, TAD880-84VE
• Volvo Penta TADH880-82GE, TADH880-84VE
• Volvo Penta TAD540-42VE
• Volvo Penta TAD550-51VE
• Volvo Penta TAD552VE
• Volvo Penta TAD580-83VE
• Volvo Penta TAD841-43GE
• Volvo Penta TAD850-52VE
• Volvo Penta TAD851-53GE
• Volvo Penta TAD853VE
• Volvo Penta TAD870-73VE
