21274883 Check Valve | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta non-return valve used in the SOLAS-compliant inlet and exhaust arrangement on D3-110I-B engines. The valve permits flow in the intended direction while preventing reverse movement that could compromise air intake or protection-system operation.

🚤 Compatibility

Typically suits:

• Volvo Penta D3-110I-B
• Volvo Penta D3-110I-C
• Volvo Penta D3-130I-C
• Volvo Penta D3-130A-B
• Volvo Penta D3-160A-B
• Volvo Penta D3-130A-C
• Volvo Penta D3-160A-C
• Volvo Penta D3-190A-B
• Volvo Penta D3-190A-C
• Volvo Penta D3-190I-A
• Volvo Penta D3-160I-C
• Volvo Penta D3-190I-B
• Volvo Penta D3-190I-C
• Volvo Penta D3-130I-B
• Volvo Penta D3-160I-B

• Engine Family: D
• HP Range: 110-190 HP

⚙️ Key Features

• Genuine Volvo Penta check valve
• Confirmed D3-110I-B SOLAS application
• One-way flow control
• Marine intake-system compatible construction
• Match the SOLAS intake assembly and hose orientation
• Engine type: Volvo Penta D3 five-cylinder common-rail marine diesel

🔌 Function

Allows controlled one-way airflow or drainage and blocks reverse flow in the SOLAS intake assembly.

⚠️ Common Signs of Failure

• Pressure or flow outside specification
• Leakage through the valve body or connections
• Valve sticking open or closed
• Repeated alarms, unstable operation or loss of system protection
• Corrosion, contamination or damaged sealing surfaces

🛠️ Service Notes

• Note which way round the valve sits before removing it and fit the replacement the same way — a non-return valve installed backwards will block flow entirely or allow the drain-back it was there to prevent
• Work clean and fit new sealing washers or O-rings on the connections; a small amount of debris is enough to hold a check valve off its seat
• Check the new valve moves freely and seals in the reverse direction before fitting, and blow or flow test it in the correct direction if you are unsure of its orientation
• Hold the valve by its hex or flats when tightening, never by clamping the body, and tighten to the figure given in the workshop manual for your engine
• Run the system afterwards and confirm the symptom has gone as well as that the joints are dry

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 21274883 → Supersedes 3889069

OEM / Related Numbers

• 3889069 earlier number superseded by this part
• 21171248 - associated air-filter assembly
• 21171277 - air-filter insert
• 21227304 - related valve used elsewhere in the system
• 21274890 - associated hose references
• 21829545 - associated hose references

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
