21339642 Set Screw | Genuine Volvo Penta Part

21339642 Set Screw | Genuine Volvo Penta Part

$93.60 AUD
$93.60 AUD
Sale Sold out
Shipping calculated at checkout.

In stock — Australian warehouse

Typically reaches our store in 3–5 business days

Availability checked daily with Volvo Penta

✓ Authorised Volvo Penta Dealer · Genuine Volvo Penta parts · Ships Australia-wide

🔧 Product Description

Genuine Volvo Penta position-specific set screw used in the IPS2-A clutch and propeller-shaft assembly. It retains or adjusts its assigned internal component and must be installed with the specified locking procedure and torque because incorrect protrusion can affect clutch movement or shaft retention.

🚤 Compatibility

Typically suits:

  • Volvo Penta D11C2-A MP
  • Volvo Penta D13C2-B MP
  • Volvo Penta D13C2-A MP
  • Volvo Penta D13C4-A MP
  • Volvo Penta D13B-L MP
  • Volvo Penta D13B-G MP
  • Volvo Penta D13B-K MP
  • Volvo Penta D13B-C MP
  • Volvo Penta D13C6-A MP
  • Volvo Penta D11B2-A MP
  • Volvo Penta D11A-C MP
  • Volvo Penta D11A-D MP
  • Volvo Penta D11A-E MP
  • Volvo Penta D13C4-B MP
  • Volvo Penta D13C5-B MP
  • Volvo Penta D13C5-A MP
  • Volvo Penta D8A4-A MP
  • Volvo Penta IPS2-A
  • Volvo Penta IPS2-B
  • Volvo Penta IPS3-A
  • Engine Family: D, IPS

⚙️ Key Features

  • Genuine Volvo Penta IPS2-A internal set screw
  • Illustrated clutch/shaft assembly
  • Correct thread, length and locking geometry
  • Used beside calibrated clutch discs, shims and shaft hardware
  • Install only to the Volvo Penta service specification
  • Engine type: Volvo Penta IPS marine propulsion system

🔌 Function

Retains or locates the assigned clutch/shaft component at the specified axial position.

⚠️ Common Signs of Failure

  • Clutch engagement becoming slow, harsh or slipping under load
  • Knocking or rattling from the clutch and shaft area
  • Screw found backed off or its locking compound broken on inspection
  • Thread or screw tip found damaged, picked up or distorted
  • Excessive end float in the shaft assembly the screw locates

🛠️ Service Notes

  • Set only to the Volvo Penta service specification - protrusion controls clutch movement and shaft retention, so a guessed setting is not safe
  • Renew the screw if the locking patch or compound has been disturbed rather than reusing it

🔄 Supersession & Cross Reference

OEM / Related Numbers

  • 3818911 - bearing housing
  • 3884689 - position-specific shims
  • 3884690 - position-specific shims
  • 3884691 - position-specific shims
  • 3817684 - cylinder
  • 3883485 - lock ring
  • 21397310 - spring references
  • 21177270 - spring references
  • 21376960 - clutch-disc kit references
  • 3817660 - clutch-disc kit references
  • 994421 - O-ring
  • 40005557 - piston ring
  • 21482105 - piston references
  • 22906676 - piston references
  • 3817680 - hub references
  • 22933883 - hub references
  • 21688052 - shaft references
  • 22387422 - shaft references
  • 22933879 - shaft references
  • 3818303 - cam disc
  • 969077 - round nut

📦 Condition

  • Genuine Volvo Penta part
  • Brand new
  • Supplied in original or equivalent packaging
