21433622 Propeller Kit | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta type Q2 nibral propeller set for Volvo Penta IPS 3, IPS 30, specifically developed for IPS with D13 engines to give outstanding efficiency, onboard comfort and manoeuvrability. The set supplies the matched three-blade front propeller and four-blade rear propeller together. Volvo Penta IPS turns the propellers round to a forward-facing position, so the twin counter-rotating propellers pull the boat through the water rather than push it, and optimal interaction between the front and rear propeller holds performance and fuel efficiency across the whole speed range.

🚤 Compatibility

Typically suits:

• Volvo Penta D13C2-B MP
• Volvo Penta D13C2-A MP
• Volvo Penta D13C4-A MP
• Volvo Penta D13B-L MP
• Volvo Penta D13B-G MP
• Volvo Penta D13B-K MP
• Volvo Penta D13B-C MP
• Volvo Penta IPS30-E
• Volvo Penta D13C6-A MP
• Volvo Penta IPS3-C
• Volvo Penta D13C4-B MP
• Volvo Penta D13C5-B MP
• Volvo Penta D13C5-A MP
• Volvo Penta IPS30-D
• Volvo Penta IPS3-A
• Volvo Penta D13C7-B MP
• Volvo Penta D13C8-B MP

• Engine Family: D, IPS
• HP Range: Approximately 0-700 HP
• Year Range: Approximately 2012 onward

⚙️ Key Features

• Type Q2 matched front and rear set for IPS 3 and IPS 30
• Nibral nickel-bronze-aluminium alloy, the Type Q/QS series for IPS with D13 engines
• 91.172 kg
• Front propeller 21433602 and rear propeller 21433612 supplied together
• 17 applications across the D13 MP engines and IPS3 / IPS30 drives
• Includes line cutter
• Includes flow deflector to reduce shaft seal wear
• Extremely strong and specially developed nibral (nickel-bronze-aluminium) alloy.
• Minimum growth, excellent durability and corrosion resistance.
• Patented flow deflector minimizes pressure and wear on propeller shaft seals.
• Three-blade front propeller and four-blade rear propeller.
• Fully CNC machined for exact tolerances and perfect geometry.
• Precise balancing for minimal vibration, quiet running and less wear on the drivetrain.
• The type Q/QS propeller is type approved by DNV for D13 IPS900, IPS1050, IPS1200 and IPS1350.
• Supplied as a matched front and rear pair.
• Material: nibral
• Fits: Volvo Penta IPS 3, IPS 30 (D13 engines)
• Type: Q2
• Set contains: front 21433602, rear 21433612

📋 Kit Contents

• 1 × Type Q2 front propeller - 21433602
• 1 × Type Q2 rear propeller - 21433612
• Propeller cone, nuts and installation hardware are serviced separately
• Related IPS3 propeller-cone kit - 21297787

🔌 Function

Supplies both halves of the pod's counter-rotating pair, sized as one unit so the two propellers share the load the way the drive was designed for and let the engine reach its rated wide-open-throttle speed. Changing size changes how hard the engine has to work, which is what the Q2 designation records.

⚠️ Common Signs of Failure

• Vibration caused by bent blades, impact damage or an unmatched pair
• Corrosion, blade-edge erosion or hub damage
• Unequal loading after replacing only one propeller with the wrong Q size

🛠️ Service Notes

• Both propellers of a drive must carry the same designation - fitting a Q2 propeller against any other size loads the engine wrongly, so renew the pair together and check the marking on each before fitting
• The Q2 front 21433602 and rear 21433612 are published at 34.927 kg and 54.885 kg, 1.36 kg less than the 91.172 kg published for the set, so the figures do not reconcile - order by the Q2 designation, never by weight
• For commercial running in polluted or debris-laden water Volvo Penta also lists the QE series, which has thicker blades than the Q for extra strength at a slight cost in top speed, and is approved for D13 IPS900, IPS1050 and IPS1200
• The type Q/QS series runs QS4, QS5, Q1, Q2, Q3, Q4, Q5, Q6, Q7, Q8 from moderate top speed to high top speed; Q2 sits of 10 on that scale.
• Both propellers on a drive must carry the same type code - the front and rear are matched for torque distribution and mixing codes changes how the load is shared.
• Line cutter 21686496 is the one listed for Volvo Penta IPS 3, IPS 30.
• Volvo Penta water-resistant multi-purpose premium grease is recommended for propeller shafts and all other propeller components.

🔄 Supersession & Cross Reference

OEM / Related Numbers

• 21433602 front propeller
• 21433612 rear propeller
• 21297787 related propeller-cone kit

Other-Brand OEM Numbers

• VOE21433622

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
