🔧 Product Description
A pressure-rated hydraulic hose used in the electronically controlled steering circuit of the Volvo Penta DPH-C sterndrive. This hose occupies.
🚤 Compatibility
Typically suits:
- Volvo Penta DPH-D1
- Volvo Penta D6-330A-F
- Volvo Penta D6-370A-F
- Volvo Penta D4-260A-F
- Volvo Penta D4-300A-F
- Volvo Penta D6-300A-F
- Volvo Penta D4-225A-F
- Volvo Penta D6-300A-G
- Volvo Penta D6-340A-G
- Volvo Penta D6-380A-G
- Volvo Penta D6-400A-G
- Volvo Penta D6-400A-F
- Volvo Penta D4-150A-G
- Volvo Penta D4-230A-G
- Volvo Penta D4-270A-G
- Volvo Penta D4-300A-G
- Engine Family: DPH, D
- HP Range: 150-400 HP
⚙️ Key Features
- Factory-crimped hydraulic fittings
- Pressure- and oil-resistant construction
- Correct length and routing for the assigned DPH-C connection
- Designed to accommodate sterndrive steering movement
🔌 Function
The hose transfers hydraulic fluid between the steering valve, control block and actuator so the sterndrive can move to the commanded steering angle.
⚠️ Common Signs of Failure
- Hydraulic-fluid seepage
- Heavy or erratic steering
- Cracked or abraded outer covering
- Air entering the hydraulic circuit
- Leakage around a crimped fitting
- Falling steering-fluid level
🛠️ Service Notes
- Fit hoses only to clean, sound spigots — take off old rubber, scale and corrosion, and renew the spigot or pipe if it is pitted, because no clamp will seal a rough sealing face
- Push the hose fully home so the clamp sits behind the bead or barb rather than over the end of the spigot, and fit new clamps whenever a hose is renewed
- Let the hose follow its natural bend with no kinks and no tension on either connection, clear of hot surfaces and moving parts, with chafe protection wherever it passes a bracket, edge or bulkhead
- Use the correct grade of hose for the duty, and clamp to the standard the installation demands — twin clamps are normal practice on seawater and fuel connections below the waterline
- Refill, vent and run the engine, then check every joint hot and cold and recheck the clamps after the first running period as the hose beds down
🔄 Supersession & Cross Reference
OEM Supersession Chain
- 21453315 → Supersedes 21199262
OEM / Related Numbers
- 21453317 - Companion steering hose
- 21453319 - Pressure hose
- 21453321 - Return hose
- 21445595 - Steering valves
- 21914259 - Steering valves
- 21469067 - Steering control unit
- 21584276 - Hydraulic filter
📦 Condition
- Genuine Volvo Penta part
- Brand new
- Supplied in original or equivalent packaging
