21467499 Fuel Pipe | Genuine Volvo Penta Part

🔧 Product Description

A rigid formed fuel pipe used in the high-pressure pump and cross-connection assembly on selected Volvo Penta D3 common-rail engines.

🚤 Compatibility

• Engine Family: D
• HP Range: 110-220 HP

Full model list at the end of this description.

⚙️ Key Features

• Genuine Volvo Penta fuel pipe
• Precision-formed for the original pump and housing
• Designed for common-rail fuel pressure
• Uses sealing O-ring 976011 where specified
• Must be installed without twisting or bending
• Engine type: D3 five-cylinder turbocharged common-rail marine diesel

🔌 Function

Carries pressurised diesel fuel between the high-pressure pump and adjoining common-rail fuel component.

⚠️ Common Signs of Failure

• Diesel leakage at the union
• Fuel-pressure fault
• Engine misfire or derate
• Pipe cracking caused by vibration or incorrect installation

🛠️ Service Notes

• Work clean: cap or plug every open union and injector as soon as it is disconnected, and fit the new pipe straight from its packaging — dirt introduced at a fuel joint is the most common cause of trouble afterwards
• Offer the pipe up so it lines up on both unions without strain, and never bend, twist or reshape a pipe to make it fit; a pipe that has been sprung into place fatigues and cracks in service
• High-pressure delivery pipes are treated as single-use in workshop practice — the union faces seal by deforming, so refit new pipes rather than reusing them, and tighten to the figure and sequence in the workshop manual for your engine
• Refit all original support clips and brackets in their proper positions so the pipe cannot chafe or vibrate against surrounding parts
• Bleed the system, then check the joints for leaks with the engine running and again once warm — never search for a diesel leak by hand, since fuel at injection pressure will penetrate skin

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 21467499 → Supersedes 21412232 → Supersedes 21301032

OEM / Related Numbers

• 21412232 earlier number superseded by this part
• 976011 - O-ring
• 36002064 - high-pressure pump
• 31259211 - housing
• 30777586 - cross connection
• 30777529 - control valve
• 31272619 - fuel temperature sensor

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D3-220I-G, D3-140A-D, D3-170A-D, D3-200A-D, D3-220A-D, D3-140I-D, D3-140A-E, D3-170A-E, D3-200A-E, D3-220A-E, D3-140I-E, D3-140A-F, D3-170A-F, D3-200A-F, D3-220A-F, D3-140I-F, D3-140A-G, D3-170A-G, D3-200A-G, D3-220A-G, D3-140I-G, D3-110I-D, D3-150I-D, D3-170I-D, D3-200I-D, D3-220I-D, D3-110I-E, D3-150I-E, D3-170I-E, D3-200I-E, D3-220I-E, D3-110I-F, D3-150I-F, D3-170I-F, D3-200I-F, D3-220I-F, D3-110I-G, D3-150I-G, D3-170I-G, D3-200I-G, D3-110I-H, D3-140A-H, D3-170A-H, D3-200A-H, D3-220A-H, D3-150I-H, D3-170I-H, D3-200I-H, D3-220I-H, D3-140I-H
