21522417 Shim | Genuine Volvo Penta Part
21522417 Shim | Genuine Volvo Penta Part
Couldn't load pickup availability
In stock — Australian warehouse
Typically reaches our store in 3–5 business days
Availability checked daily with Volvo Penta
✓ Authorised Volvo Penta Dealer · Genuine Volvo Penta parts · Ships Australia-wide
🔧 Product Description
A precision 0.15mm shim used in applicable Volvo Penta DPH and DPR universal-joint and bearing-carrier assemblies. It allows the technician to establish the specified bearing preload or shaft end float after measuring the assembled components.
🚤 Compatibility
Typically suits:
- Volvo Penta DPH-D1
- Volvo Penta D6-330A-F
- Volvo Penta D6-370A-F
- Volvo Penta D4-260A-F
- Volvo Penta D4-300A-F
- Volvo Penta D6-300A-F
- Volvo Penta D4-225A-F
- Volvo Penta D6-300A-G
- Volvo Penta D6-340A-G
- Volvo Penta D6-380A-G
- Volvo Penta DPH-E
- Volvo Penta D6-400A-G
- Volvo Penta D6-400A-F
- Volvo Penta D4-150A-G
- Volvo Penta D4-230A-G
- Volvo Penta D4-270A-G
- Volvo Penta D4-300A-G
- Engine Family: DPH, D
- HP Range: 150-400 HP
- Year Range: Approximately 2009 - 2020 production-era applications
⚙️ Key Features
- Precision adjustment shim for Volvo Penta sterndrives
- Nominal thickness: 0.15mm
- Used in bearing-carrier and universal-joint setup
- Supports correct shaft position and bearing life
- Engine type: Volvo Penta DPH / DPR sterndrive
- TH=0.15mm (Volvo assembly listing)
🔌 Function
Adjusts the axial stack height of the bearing assembly to produce the specified preload or end float.
⚠️ Common Signs of Failure
- Bearing noise or gear whine
- Excessive shaft movement
- Bearing overheating after service
- Seal leakage caused by incorrect shaft position
- Premature bearing wear or metal contamination
🛠️ Service Notes
- Shims are supplied in graded thicknesses and exist to bring a setting into specification, so measure with a micrometer and select the thickness the setting procedure for your engine calls for rather than matching one by eye
- Note which shim came from which position on removal and keep them identified — once an assembly has bedded in, shims are not interchangeable between positions
- Check both faces are clean, flat and free of burrs, corrosion and old sealant before fitting; dirt trapped under a shim shifts the setting as surely as the wrong thickness does
- Discard any shim that is dished, cracked, pitted or fretted rather than reusing it, and make sure no old shim has been left behind in the recess
- Recheck the clearance or setting after the assembly is tightened down, because clamping load can change the measurement you took loose
🔄 Supersession & Cross Reference
OEM Supersession Chain
- 21522417 → Supersedes 3863319
OEM / Related Numbers
- 3863317 earlier number superseded by this part
- 3863319 earlier number superseded by this part
- 3887297 - complete universal joint
- 3843136 - universal-joint spider kit
- 3860364 - retaining screw
- 3863084 - sealing ring
- 11043 - roller bearing
- 21511540 - bearing box
- 984258 - screw
- 21522416 - 0.10mm shim
- 21522419 - 0.225mm shim
- 21522420 - 0.25mm shim
Aftermarket / Verified Equivalents
- SLP: SHI-417
📦 Condition
- Genuine Volvo Penta part
- Brand new
- Supplied in original or equivalent packaging
