21522941 Bracket | Genuine Volvo Penta Part

🔧 Product Description

A genuine mounting bracket used to support the transmission oil cooler in Volvo Penta D3 marine installations equipped with HS25, HS45 or ZF45-1 marine transmissions. It maintains cooler position and hose alignment while resisting vibration from the engine and gearbox.

🚤 Compatibility

• Engine Family: D
• HP Range: 110-220 HP
• Year Range: Approximately 2004 - 2020

Full model list at the end of this description.

⚙️ Key Features

• Genuine Volvo Penta oil-cooler mounting bracket
• Used in D3 transmission connecting-component installations
• Supports the cooler and reduces load on oil hoses
• Factory mounting-hole spacing and component clearance
• Direct replacement for a bent, cracked or corroded original bracket
• Engine type: 2.4L inline five-cylinder common-rail marine diesel with mechanical marine transmission

🔌 Function

Supports the transmission oil cooler in the correct position, preserving hose routing and preventing vibration loads from being transferred into the cooler connections.

⚠️ Common Signs of Failure

• Oil cooler movement or vibration
• Rattling from cracked metal or loose fasteners
• Oil-hose chafing or misalignment
• Fatigue cracking around the mounting holes
• Cooler or hose damage after bracket corrosion or distortion

🛠️ Service Notes

• Offer the bracket up and start every fastener by hand before tightening any of them, so the component is not pulled into a strained position
• Check the mating faces are clean, flat and free of corrosion scale — a bracket that does not sit flat will work loose and let the component move
• Renew self-locking nuts, lock washers, tab washers or thread-locking compound wherever the original assembly used them, and tighten to the figure given in the workshop manual for your engine
• Where the bracket carries a rubber mount or bush, renew that at the same time rather than reusing a perished one
• On brackets in the inlet and exhaust area, never force alignment to make the holes line up — cure the misalignment at its source, or the bracket and the component it holds will both crack

🔄 Supersession & Cross Reference

OEM / Related Numbers

• 21149930 - oil cooler
• 3584428 - oil hose
• 963948 - nipple
• 941750 - nipple
• 21121914 - gasket
• 22371868 - oil hose
• 961673 - hose clamp
• 961669 - hose clamp
• 21643849 - spacer

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D3-220I-G, D3-140I-D, D3-140I-E, D3-140I-F, D3-140I-G, D3-110I-D, D3-150I-D, D3-170I-D, D3-200I-D, D3-220I-D, D3-110I-E, D3-150I-E, D3-170I-E, D3-200I-E, D3-220I-E, D3-110I-F, D3-150I-F, D3-170I-F, D3-200I-F, D3-220I-F, D3-110I-G, D3-150I-G, D3-170I-G, D3-200I-G, D3-110I-H, D3-150I-H, D3-170I-H, D3-200I-H, D3-220I-H, D3-140I-H
