21535352 Lip Seal | Genuine Volvo Penta Part

🔧 Product Description

A rotary lip seal installed in the extension or intermediate-housing assembly of first-generation Volvo Penta IPS drives. It seals the rotating interface against seawater ingress and lubricant loss.

🚤 Compatibility

• Engine Family: D, IPS
• HP Range: 260-480 HP

Full model list at the end of this description.

⚙️ Key Features

• Genuine Volvo Penta IPS drive seal
• Application-specific sealing-lip profile
• Designed for continuous marine immersion and drive lubricant exposure
• Correct interference fit for the original housing
• Replace whenever the adjoining shaft, bearing or housing is removed
• Engine type: Volvo Penta IPS pod drive
• 2 used per assembly

🔌 Function

Maintains the fluid-tight barrier around the rotating extension-housing interface.

⚠️ Common Signs of Failure

• Water contamination in the drive lubricant
• Lubricant leakage from the intermediate housing
• Milky or emulsified drive oil
• Corrosion near the shaft or bearing
• A hardened, torn or grooved sealing lip

🛠️ Service Notes

• Note which way round the old seal sits before you pull it out; a lip seal only holds one way and fitting it reversed guarantees a leak
• Check the shaft or wear sleeve the seal runs on — a groove worn by the old seal, or any burr, nick or rust in the running band, will cut a new seal straight away
• Clean the housing bore, then press the seal in square using a drift or tool that bears on the outer face of the seal, never on the lip, and take it to the depth the original sat at
• Lightly oil or grease the lip and the shaft before assembly so the seal is not run dry on start-up, and keep grit away from the lip
• Sleeve or tape over splines, keyways, threads and step edges when passing the seal over them, and never lever the lip past an edge with a screwdriver

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 21535352 → Supersedes 21452859 → Supersedes 3861819

OEM / Related Numbers

• 21452859 earlier number superseded by this part
• 3861819 earlier number superseded by this part
• 3808841 - intermediate housing
• 184093 - needle roller bushing
• 184863 - needle roller bearing
• 21419026 - related plate
• 3861697 - gear segment
• 3862569 - guide sleeve
• 21259197 - water inlet kit
• 21259401 - water inlet
• 21259405 - plate

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D6-330D-E, D6-370D-E, D6-330D-C, D6-370D-C, D6-330D-D, D6-370D-D, D6-330D-F, D6-370D-F, D6-300D-F, D6-310D-D, D6-310D-C, D6-310D-E, D6-300D-G, D6-340D-G, D6-380D-G, D6-440D-G, D6-480D-G, D6-435D-D, D6-435D-E, D6-435D-F, D6-435D-C
• Volvo Penta D4-260D-C, D4-260D-D, D4-260D-E, D4-260D-F, D4-300D-C, D4-300D-D, D4-300D-E, D4-300D-F
• Volvo Penta IPS-A, IPS-B, IPS-C, IPS-D, IPS-E, IPS-F
• Volvo Penta 8.1IPSCE-MF, 8.1IPSCE-P, 8.1IPSCE-Q
• Volvo Penta IPS10-A, IPS10-B
