21609813 Hose Clamp | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta stainless steel hose clip, listed as the recommended clip for rubber exhaust hose 1140673 - the largest size in the exhaust range at 205 mm internal diameter and 217 mm external diameter, with a 1200 mm minimum bend radius. It weighs 0.329 kg, is listed for 44 applications across the D13, D16 and IPS ranges and supersedes clamp 3595396.

🚤 Compatibility

• Engine Family: D, IPS

Full model list at the end of this description.

⚙️ Key Features

• Recommended stainless steel clip for exhaust hose 1140673
• Suits the 205 mm internal, 217 mm external diameter hose
• 0.329 kg
• Supersedes 3595396
• 44 applications across the D13, D16 and IPS ranges
• Fits: Rubber exhaust hose 1140673 (205 mm internal diameter)

🔌 Function

Applies even clamping load around a large-diameter wet exhaust joint so the hose is retained and neither exhaust gas nor cooling water can escape.

⚠️ Common Signs of Failure

• Exhaust or cooling water seepage at the hose joint
• Band corroded, stretched or distorted
• Clip will not hold its tightening torque
• Hose creeping on the spigot or the joint separating
• Uneven clamping where the band has been fitted over the hose bead

🛠️ Service Notes

• The clips are listed against the hose size: 3817828 suits the 127 mm hose, 3595350 the 152 mm hose and this one the 205 mm hose
• Renew clips with the hose and retighten after the first heat cycle

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 21609813 → Supersedes 3595396

OEM / Related Numbers

• 3595396 earlier number superseded by this part
• 1140673 wet-exhaust hose
• 21227464 exhaust hose
• 3889352 propeller shaft catalogue-linked reference

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D13C3-B MH, D13C1-B MH, D13C4-B MH, D13C2-B MP, D13C1-A MP, D13C2-A MP, D13C3-A MP, D13C4-A MP, D13B-L MP, D13B-E MG, D13B-E MG (FE), D13B-E MH, D13B-E MH (FE), D13B-F MG, D13B-F MG (FE), D13B-G MP, D13B-K MP, D13B-N MH, D13B-N MH (FE), D13B-C MP, D13C4-B MP, D13C5-B MP, D13C6-A MP, D13C1-A MH, D13C2-A MH, D13C1-B MG, D13C3-B MG, D13C4-B MG, D13C2-B MG, D13C5-A MP, D13C2-A MG, D13C1-A MG, D13C7-B MP, D13C8-B MP, D13C9-A MP
• Volvo Penta D16C1-E MG, D16C2-E MG, D16C1-E MH, D16C1-F MH, D16C2-E MH
• Volvo Penta IPS3-C, IPS3-A
• Volvo Penta IPS30-E, IPS30-D
