21611344 Cover | Genuine Volvo Penta Part

🔧 Product Description

Heat-exchanger end/top cover used on the listed Volvo Penta D13 marine generator installations. It closes the exchanger assembly and works with the specified plate, gasket, O-ring and fasteners to contain coolant and seawater passages.

🚤 Compatibility

Typically suits:

• Volvo Penta D13C3-B MH
• Volvo Penta D13C1-B MH
• Volvo Penta D13B-E MG
• Volvo Penta D13B-E MG (FE)
• Volvo Penta D13B-E MH
• Volvo Penta D13B-E MH (FE)
• Volvo Penta D13B-N MH
• Volvo Penta D13B-N MH (FE)
• Volvo Penta D13C1-A MH
• Volvo Penta D13C1-B MG
• Volvo Penta D13C3-B MG
• Volvo Penta D13C1-A MG
• Volvo Penta D16C1-E MH
• Volvo Penta D16C1-F MH

• Engine Family: D

⚙️ Key Features

• Genuine Volvo Penta heat-exchanger cover
• Used with exchanger references 21404010 or 21346489
• Application-specific passage and bolt geometry
• Works with top plate 21111056 and sealing components
• Inspect mating faces for corrosion before installation
• Engine type: 13-litre inline six-cylinder diesel marine generator set

🔌 Function

Closes the heat-exchanger end/top section and directs coolant and seawater through the intended internal passages.

⚠️ Common Signs of Failure

• Coolant or seawater leakage around the cover
• Corrosion or pitting at sealing faces
• Cross-leakage between exchanger circuits
• Repeated gasket/O-ring failure

🛠️ Service Notes

• Clean both sealing faces back to clean metal and check the cover for distortion, cracks or pulled bolt holes before refitting — a warped flange will not seal even with a new gasket
• Where the joint uses a gasket, seal or O-ring, always fit a new one and seat it dry unless the workshop manual for your engine specifies a sealant; never try to make a poor joint tight with extra sealant
• Tighten the fasteners progressively and evenly, working out from the centre, to the figure given in the manual for your engine — pressed steel, alloy and plastic covers distort easily if pulled down hard or unevenly
• If the cover carries a shaft seal or bearing, support it square to the shaft as it goes on so the seal lip is not nicked or rolled over
• Check that any breather, drain or oil return passage in the cover is clear before final tightening, and look for leaks once the engine has been run up to temperature

🔄 Supersession & Cross Reference

OEM / Related Numbers

• 21404010 heat exchanger
• 21346489 heat exchanger
• 21111056 top plate
• 21242902 gasket
• 925064 O-ring
• 984735 flange screw

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
