21809318 Control Panel | Genuine Volvo Penta Part

🔧 Product Description

The Boat Trim System (BTS), with its patented interceptor technology, gives perfect control over pitch and heel with rapid response, quicker onto plane, lower fuel consumption and a more comfortable ride. Add the Automatic Boat Trim option and the system takes over the task of keeping the boat correctly trimmed automatically. It is a match for almost all planing boats in the range of 17 to 40+ feet - outboard, sterndrive or inboard - and its compact design makes for an easy installation. The control panel is the intuitive, user-friendly helm interface for the system. It is a mandatory component of every installation and is already included in both the 300 mm and 450 mm kits.

🚤 Compatibility

• Engine Family: D
• HP Range: 145-480 HP

Full model list at the end of this description.

⚙️ Key Features

• One panel per helm station, up to four stations
• Already included in the 300 mm and 450 mm Boat Trim System kits
• Each extra station also needs a 6-pole Y-cable and a 6-pole extension cable
• 0.268 kg
• Listed for 27 applications across the D4 and D6 ranges
• Intuitive, user-friendly control panel
• Mandatory component of every Boat Trim System installation
• One per helm station - one for a single-station boat, two for a two-station boat
• Up to four helm stations are possible
• Fits: Volvo Penta Boat Trim System installations

📋 Kit Contents

• 1 × Boat Trim System control panel - 21809318
• Control unit, interceptor units, cables, GPS receiver and attitude-control components are separate unless supplied in a complete BTS package

🔌 Function

Provides four-button control for bow down, bow up, port list and starboard list adjustment, and displays port and starboard interceptor position on supported installations.

⚠️ Common Signs of Failure

• Buttons or keys do not respond
• Intermittent display or warning functions
• Water entry or condensation
• Damaged connector pins or backlighting

🛠️ Service Notes

• Adding a second helm station means a panel, a 6-pole Y-cable and a 6-pole extension cable together - 3588972 is the Y-cable in this run
• The 450 mm kit 23983555 already contains one panel, so only count the extra stations
• Each extra helm station also needs one 6-pole Y-cable and one 6-pole extension cable
• Already supplied in the 300 mm kit 21914554 and the 450 mm kit 23983555, so only count the extra stations

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 21809318 → Supersedes 21508559 → Supersedes 40005632 → Supersedes 3847462 → Supersedes 1140717

OEM / Related Numbers

• 21508559 earlier number superseded by this part
• 40005632 earlier number superseded by this part
• 3847462 earlier number superseded by this part
• 1140717 earlier number superseded by this part
• Used in Boat Trim System 300 mm and 450 mm component arrangements
• 21546221 - BTS control unit
• 3817171 - 2.5 m cable
• 3817172 - 4 m cable
• 874789 - 5 m cable
• 889551 - 9 m cable
• 3847459 - GPS receiver used in automatic trim configurations

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D6-340I-G, D6-380I-G, D6-440I-G, D6-480I-G, D6-300A-G, D6-340A-G, D6-380A-G, D6-440I-WJ-G, D6-480I-WJ-G, D6-300D-G, D6-340D-G, D6-380D-G, D6-440D-G, D6-480D-G, D6-400A-G, D6-440A-G, D6-300I-G
• Volvo Penta D4-175I-G, D4-230I-G, D4-270I-G, D4-320I-G, D4-300I-G, D4-230A-G, D4-270A-G, D4-320A-G, D4-300A-G, D4-145I-G
