22023226 Wiring Harness | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta 1.7m D11A-D IPS / Jackshaft Wiring Harness, part number 22023226. A genuine 1.7-metre wiring harness used in Volvo Penta D11A-D marine propulsion, IPS or jackshaft installations.

🚤 Compatibility

• Engine Family: D, IPS
• HP Range: Approximately 625-725 HP
• Year Range: Approximately 2007 - 2015

Full model list at the end of this description.

⚙️ Key Features

• 1700 mm long
• For D11A-D propulsion, IPS and jackshaft installations
• 2.223 kg
• Supersedes 21851490, 21851491 and 22023225
• Listed for 22 D series and IPS applications
• L=1700mm (Volvo assembly listing)
• Also supersedes Volvo part number 21761782

🔌 Function

Carries power and signal between the engine, the driveline and the control equipment over a 1700 mm run, in a loom terminated for that length.

⚠️ Common Signs of Failure

• Intermittent faults or warnings that come and go with engine vibration
• Green or white corrosion inside a connector, or a pin pushed back in its housing
• Chafed, cut or heat damaged outer sheath where the loom passes a bracket or hot pipe
• A circuit reading open or high resistance when the loom is moved by hand
• Water tracking into a connector after immersion or wash down

🛠️ Service Notes

• Supersedes 21851490, 21851491 and 22023225, so the later number covers all three
• Harnesses 22023228, 22023230 and 22023231 cover the same installation at 2600, 3500 and 5500 mm, so measure the run before ordering
• Support the loom at every original clip and keep it clear of hot pipes and sharp edges - chafe is the usual cause of a repeat fault

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 22023226 → Supersedes 21851490 → Supersedes 21761780

OEM / Related Numbers

• 21851491 earlier number superseded by this part
• 22023225 earlier number superseded by this part
• 21851490 earlier number superseded by this part
• 21761780 earlier number superseded by this part
• 21751128 - support bracket
• 949997 - clamp
• 994383 - flange screw
• 821542 - spacer sleeve

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D13C2-B MP, D13C2-A MP, D13C4-A MP, D13B-L MP, D13B-G MP, D13B-K MP, D13B-C MP, D13C6-A MP, D13C4-B MP, D13C5-B MP, D13C5-A MP
• Volvo Penta D11C2-A MP, D11C4-A MP, D11B4-A MP, D11B2-A MP, D11A-D MP, D11A-E MP
• Volvo Penta IPS2-C, IPS2-B
• Volvo Penta D8A4-A MP
• Volvo Penta IPS20-D
• Volvo Penta IPS3-A
