22023241 Wiring Harness | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta 2.6m EVC / IPS Steering Wiring Harness, part number 22023241. A genuine 2.6-metre wiring harness used in Volvo Penta D13 IPS and jackshaft installations, including arrangements with approximately 1500-1600mm jackshaft spacing.

🚤 Compatibility

• Engine Family: D, IPS
• HP Range: 180-435 HP
• Year Range: Approximately 2012 - current supported applications

Full model list at the end of this description.

⚙️ Key Features

• 2600 mm long
• For D13 IPS installations with a 1500 to 1600 mm jackshaft
• 0.726 kg
• Supersedes 21758219
• Listed for 62 D series and IPS applications
• L=2600mm (Volvo assembly listing)

🔌 Function

Carries power and signal between the engine, the steering and hydraulic control unit and the IPS drive over a 2600 mm run, in a loom terminated for that installation.

⚠️ Common Signs of Failure

• Steering or drive warnings that come and go with engine vibration
• Corrosion or moisture inside a connector shell
• Chafed or heat damaged sheath along the run to the drive
• A circuit reading open or high resistance when the loom is moved
• Pins found bent, pushed back or corroded in the housing

🛠️ Service Notes

• Supersedes 21758219
• The published weights across this group of steering harnesses do not run in step with their lengths, so order by the quoted length and the jackshaft spacing and not by mass
• Route the new loom exactly as the old one lay and clip it at every original point

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 22023241 → Supersedes 21758219

OEM / Related Numbers

• 21758219 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D13C3-B MH, D13C1-B MH, D13C4-B MH, D13C2-B MP, D13C1-A MP, D13C2-A MP, D13C3-A MP, D13C4-A MP, D13B-L MP, D13B-E MG, D13B-E MG (FE), D13B-E MH, D13B-E MH (FE), D13B-F MG, D13B-F MG (FE), D13B-G MP, D13B-K MP, D13B-N MH, D13B-N MH (FE), D13B-C MP, D13C4-B MP, D13C5-B MP, D13C6-A MP, D13C1-A MH, D13C2-A MH, D13C1-B MG, D13C3-B MG, D13C4-B MG, D13C2-B MG, D13C5-A MP, D13C2-A MG, D13C1-A MG, D13C7-B MP, D13C8-B MP
• Volvo Penta D6-330A-F, D6-370A-F, D6-330D-F, D6-370D-F, D6-300A-F, D6-300D-F, D6-300I-F, D6-330I-F, D6-370I-F, D6-435D-F, D6-400A-F, D6-435I-F
• Volvo Penta D4-260A-F, D4-260D-F, D4-260I-F, D4-300A-F, D4-300D-F, D4-180I-F, D4-225I-F, D4-300I-F, D4-225A-F
• Volvo Penta D11B3-A MP, D11B4-A MP, D11B2-A MP, D11B1-A MP
• Volvo Penta IPS3-C, IPS3-A
• Volvo Penta IPS30-D
