22023242 Wiring Harness | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta 3.1m EVC / IPS Steering Wiring Harness, part number 22023242. A genuine 3.1-metre wiring harness used in Volvo Penta EVC-E2, HCU and IPS steering installations.

🚤 Compatibility

• Engine Family: D, IPS
• HP Range: 180-435 HP
• Year Range: Approximately 2012 - current supported applications

Full model list at the end of this description.

⚙️ Key Features

• 3100 mm long
• For D13 IPS installations with a 1900 to 2000 mm jackshaft
• 3.765 kg
• Supersedes 21758220
• Listed for 42 D series and IPS applications
• L=3100mm (Volvo assembly listing)

🔌 Function

Carries power and signal between the engine, the steering and hydraulic control unit and the IPS drive over a 3100 mm run, in a loom terminated for that installation.

⚠️ Common Signs of Failure

• Intermittent faults or alarms that follow vibration
• Green or white corrosion inside a connector
• Outer sheath rubbed through where the loom passes a bracket
• Resistance in a circuit rising when the loom is flexed
• Water tracking into a connector after immersion or wash down

🛠️ Service Notes

• Supersedes 21758220
• The jackshaft length is what separates this harness from its neighbours, so measure the shaft and the cable run before ordering
• Support the loom at every original clip - an unsupported run chafes first

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 22023242 → Supersedes 21758220

OEM / Related Numbers

• 21758220 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D13C2-B MP, D13C1-A MP, D13C2-A MP, D13C3-A MP, D13C4-A MP, D13B-L MP, D13B-G MP, D13B-K MP, D13B-C MP, D13C6-A MP, D13C4-B MP, D13C5-B MP, D13C5-A MP, D13C8-B MP
• Volvo Penta D6-330A-F, D6-370A-F, D6-330D-F, D6-370D-F, D6-300A-F, D6-300D-F, D6-300I-F, D6-330I-F, D6-370I-F, D6-435D-F, D6-400A-F, D6-435I-F
• Volvo Penta D4-260A-F, D4-260D-F, D4-260I-F, D4-300A-F, D4-300D-F, D4-180I-F, D4-225I-F, D4-300I-F, D4-225A-F
• Volvo Penta D11B3-A MP, D11B4-A MP, D11B2-A MP, D11B1-A MP
• Volvo Penta IPS3-C, IPS3-A
• Volvo Penta IPS30-D
