22023244 Wiring Harness | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta 5.5m EVC / IPS Steering Wiring Harness, part number 22023244. A genuine 5.5-metre wiring harness used in extended Volvo Penta EVC-E2, HCU and IPS steering installations.

🚤 Compatibility

• Engine Family: D, IPS
• HP Range: 180-435 HP
• Year Range: Approximately 2012 - current supported applications

Full model list at the end of this description.

⚙️ Key Features

• 5500 mm long, listed as an option length
• For extended EVC-E2, steering and hydraulic control unit and IPS installations
• 3.719 kg
• Supersedes 21858754
• Listed for 67 D series and IPS applications
• L=5500mm (Volvo assembly listing)

🔌 Function

Carries power and signal between the engine, the steering and hydraulic control unit and the IPS drive over a 5500 mm run, in a loom terminated for that installation.

⚠️ Common Signs of Failure

• Warnings or shutdowns that come and go with vibration or with movement of the loom
• Corrosion, damp or salt found inside a connector
• Chafed or heat damaged sheath along a long unsupported run
• A circuit reading open or high resistance when the loom is handled
• Connector seals perished or pins pushed back

🛠️ Service Notes

• Supersedes 21858754
• This is the long option in the steering harness group, which runs from 1300 mm upwards - measure the cable run before ordering
• Every original clip matters on a run this long, since unsupported loom is what wears through first

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 22023244 → Supersedes 21858754

OEM / Related Numbers

• 21858754 earlier number superseded by this part
• 21865234 - earlier harness reference
• 22390849 - related steering harness references
• 22390850 - related steering harness references
• 22732912 - related steering harness references
• 22732913 - related steering harness references

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D13C3-B MH, D13C1-B MH, D13C4-B MH, D13C2-B MP, D13C1-A MP, D13C2-A MP, D13C3-A MP, D13C4-A MP, D13B-L MP, D13B-E MG, D13B-E MG (FE), D13B-E MH, D13B-E MH (FE), D13B-F MG, D13B-F MG (FE), D13B-G MP, D13B-K MP, D13B-N MH, D13B-N MH (FE), D13B-C MP, D13C4-B MP, D13C5-B MP, D13C6-A MP, D13C1-A MH, D13C2-A MH, D13C1-B MG, D13C3-B MG, D13C4-B MG, D13C2-B MG, D13C5-A MP, D13C2-A MG, D13C1-A MG, D13C7-B MP, D13C8-B MP
• Volvo Penta D6-330A-F, D6-370A-F, D6-330D-F, D6-370D-F, D6-300A-F, D6-300D-F, D6-300I-F, D6-330I-F, D6-370I-F, D6-435D-F, D6-400A-F, D6-435I-F
• Volvo Penta D4-260A-F, D4-260D-F, D4-260I-F, D4-300A-F, D4-300D-F, D4-180I-F, D4-225I-F, D4-300I-F, D4-225A-F
• Volvo Penta D11C2-A MP, D11B3-A MP, D11B4-A MP, D11B2-A MP, D11A-D MP, D11A-E MP, D11B1-A MP
• Volvo Penta IPS3-C, IPS3-A
• Volvo Penta D8A4-A MP
• Volvo Penta IPS2-B
• Volvo Penta IPS30-D
