22063146 Bracket | Genuine Volvo Penta Part
22063146 Bracket | Genuine Volvo Penta Part
Couldn't load pickup availability
Available from Volvo Penta international
Typically reaches our store in 10–14 business days
Availability checked daily with Volvo Penta
✓ Authorised Volvo Penta Dealer · Genuine Volvo Penta parts · Ships Australia-wide
🔧 Product Description
Companion structural bracket for the D13 engine-mounting system. Its formed profile and mounting-hole locations position the engine support and vibration cushion at the designed height and lateral offset.
🚤 Compatibility
Typically suits:
- Volvo Penta TAD1180-83VE
- Volvo Penta TAD1170-72VE
- Volvo Penta TAD1150-52VE
- Volvo Penta TAD1140-42VE
- Engine Family: TAD
⚙️ Key Features
- Rear engine mounting bracket for the D13 installation
- 12.994 kg
- Listed for 4 applications in the TAD series
- 22063138 is the companion bracket in the same arrangement
🔌 Function
Carries the rear of the engine into the mounting rail on the opposite position to its partner, setting the vibration cushion at the designed height and lateral offset.
⚠️ Common Signs of Failure
- More vibration than usual, or the engine sitting at a changed height
- Cracks at the bolt holes or along a weld line
- Fixings that will not stay tight, or elongated fixing holes
- Vibration cushion squashed unevenly or bottomed out
- Progressive loss of alignment with the driven equipment
🛠️ Service Notes
- The 108 grams between the published weights of this bracket and 22063138 do not separate them, so order by part number and by which position is being replaced
- Fit a new vibration cushion with the bracket and re-check alignment after final tightening
🔄 Supersession & Cross Reference
OEM / Related Numbers
- 22063138 - companion engine-mounting bracket
- 22072352 - related brackets
- 22072354 - related brackets
- 22119445 - related bracket
- 17235395 - engine mounting
- 862347 - rubber cushion
- 3832463 - spacer
- 984857 - flange screws
- 984868 - flange screws
📦 Condition
- Genuine Volvo Penta part
- Brand new
- Supplied in original or equivalent packaging
