22112296 Wiring Harness | Genuine Volvo Penta Part

🔧 Product Description

Engine wiring harness used in Volvo Penta marine and stationary diesel installations. It provides factory connector branches and protected routing for sensors, actuators and control-unit circuits.

🚤 Compatibility

Typically suits:

• Volvo Penta D8A2-A MP
• Volvo Penta D8A4-A MP
• Volvo Penta IPS15-B
• Volvo Penta IPS15-A
• Volvo Penta D8A8-A MP

• Engine Family: D, IPS

⚙️ Key Features

• Factory connector and conductor layout
• Marine/stationary diesel application
• Approximate listed weight 0.849 kg
• Protected loom for oil, heat and vibration
• Engine type: Electronically controlled turbocharged diesel

🔌 Function

Carries electrical power and control signals between engine sensors, actuators, control module and installation wiring.

⚠️ Common Signs of Failure

• Multiple sensor faults
• Corroded or loose terminals
• Chafed loom
• Faults that change when the harness is moved

🛠️ Service Notes

• Compare the new harness with the old one before fitting — check the connector types, the number of pins and the branch lengths, and lay it out alongside the old loom to confirm every branch reaches its component
• Disconnect the batteries before unplugging or fitting a harness, and support the loom as you work so its weight never hangs on a connector or a bulkhead grommet
• Route it along the original path and secure it with the original clips and ties, clear of hot exhaust surfaces, sharp edges and anything that moves; leave a service loop at each connector rather than pulling a branch tight
• Push every connector home until the lock latches and protect the joints with a marine dielectric grease — an intermittent electrical fault is far more often a partly seated or salt-corroded pin than a broken wire
• Renewing the harness is the right repair where insulation is chafed, brittle or oil-soaked, or where corrosion has tracked inside the connector bodies; patch repairs in a damp engine bay tend to fail again, and any single conductor that is repaired should be joined with tinned marine cable of the same gauge, a proper crimp and adhesive-lined heat-shrink

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
