22167713 Cover Plate | Genuine Volvo Penta Part
22167713 Cover Plate | Genuine Volvo Penta Part
Couldn't load pickup availability
Available on request — contact us
As an authorised Volvo Penta dealer we can source parts through channels not shown online, and check supersession and used options for you
Availability checked daily with Volvo Penta
✓ Authorised Volvo Penta Dealer · Genuine Volvo Penta parts · Ships Australia-wide
🔧 Product Description
Genuine Volvo Penta large cover plate in stainless steel for the sailboat control, measuring 107 x 166 mm, weighing 0.751 kg and listed for 12 D1 and D2 applications. It is the plate listed for upgrading a control that already has a large cover plate, and it goes with the stainless steel lever 22576994. The black plastic plate for the same upgrade is 853713.
🚤 Compatibility
Typically suits:
- Volvo Penta D2-40
- Volvo Penta D2-40B
- Volvo Penta D2-40F
- Volvo Penta D1-30
- Volvo Penta D1-30B
- Volvo Penta D1-30F
- Volvo Penta D1-13
- Volvo Penta D1-13B
- Volvo Penta D1-13F
- Volvo Penta D1-20
- Volvo Penta D1-20B
- Volvo Penta D1-20F
- Engine Family: D
- HP Range: 13-40 HP
- Year Range: Approximately 2005 - current supported applications
⚙️ Key Features
- Large stainless steel cover plate, 107 x 166 mm
- For upgrading a sailboat control that has the large cover plate
- Fitted with stainless steel lever 22576994
- 0.751 kg
- 12 D1 and D2 applications
- The black plastic alternative is 853713
- Large cover plate, stainless steel
- For the large 107 x 166 mm cover plate size
- High quality stainless steel for the marine environment
- Fits: Volvo Penta mechanical sailboat control, large 107 x 166 mm cover plate size
📋 Kit Contents
- 22167713 - stainless cover plate
- 975691 - O-ring
- 1140094 - washer
- 975665 - O-ring
- 997781 - screw
- 996835 - screw
- 22576994 - compatible control lever, ordered separately
- 851601 - compatible control mechanism, ordered separately
- 855352 - neutral switch, ordered separately
- 22688044 - alternative small-cover control kit
- 853713 - black cover used with mechanism 1140095
🔌 Function
Closes and finishes the panel opening left when a sailboat throttle and shift control is upgraded, carrying the new control on the existing cut-out.
⚠️ Common Signs of Failure
- Old cut-out showing beyond the edge of the plate
- Plate loose or lifting at a corner
- Corrosion staining or pitting on the stainless face
- Fixing holes not lining up with the panel
- Water tracking behind the plate and into the panel
🛠️ Service Notes
- Measure the existing cut-out before ordering - the small 100 x 121 mm plate takes the separate upgrade 22688044
- If the existing control mechanism is kept, minor modifications are needed to fit this stainless steel plate, and the installation instructions detail them
- Bed the plate down on sealant and check the control moves through its full travel in both directions before closing the job up
- Mechanism 851601 is the one listed for the stainless steel cover plate
- Minor modifications to a retained control mechanism may be needed to fit the new stainless steel cover plate, as detailed in the supplied installation instructions
- 853713 is the equivalent large cover plate in black plastic, and it takes mechanism 1140095
📦 Condition
- Genuine Volvo Penta part
- Brand new
- Supplied in original or equivalent packaging
