🔧 Product Description
A genuine drive extension package for the DPH-D1 sterndrive. It extends the upper and lower drive connection while retaining the correct sealing, shimming and splined torque path.
🚤 Compatibility
Typically suits:
- Volvo Penta DPH-D1
- Volvo Penta D6-330A-F
- Volvo Penta D6-370A-F
- Volvo Penta D4-260A-F
- Volvo Penta D4-300A-F
- Volvo Penta D6-300A-F
- Volvo Penta D4-225A-F
- Volvo Penta D6-300A-G
- Volvo Penta D6-340A-G
- Volvo Penta D6-380A-G
- Volvo Penta D6-400A-G
- Volvo Penta D6-400A-F
- Volvo Penta DPR-D
- Volvo Penta D4-150A-G
- Volvo Penta D4-230A-G
- Volvo Penta D4-270A-G
- Volvo Penta D4-300A-G
- Engine Family: DPH, D, DPR
- HP Range: 150-400 HP
- Year Range: Approximately 2010s
⚙️ Key Features
- Complete DPH-D1 drive extension package
- Includes extension housing, splined sleeve, seals and shims
- Factory fastener lengths for the extended housing
- Maintains driveshaft alignment and watertight sealing
- Drive serial and transom installation must be checked
- Engine type: Volvo Penta diesel Aquamatic sterndrive
📋 Kit Contents
- Extension housing - Volvo Penta 22175326
- O-ring - Volvo Penta 925096
- Sealing ring - Volvo Penta 3862245
- Spacer ring - Volvo Penta 3862320
- Shim 0.10mm - Volvo Penta 977910
- Shim 0.15mm - Volvo Penta 977911
- Shim 0.35mm - Volvo Penta 977912
- Six-point socket screw, 75mm - Volvo Penta 984261
- Screw, 65mm - Volvo Penta 3588357
- Spacer - Volvo Penta 3587976
- Splined sleeve - Volvo Penta 22098612
- Table / housing gasket - Volvo Penta 3862249
🔌 Function
The kit extends the drive housing and splined connection while preserving shaft alignment, bearing preload and water sealing.
⚠️ Common Signs of Failure
- Extension housing or splined sleeve is damaged
- Water or lubricant leaks at the extension joint
- Incorrect shimming causes noise or end play
- Fastener threads or sealing faces are damaged
- Drive height must be changed using the approved Volvo installation
🛠️ Service Notes
- This is the complete DPH-D1 upper-drive extension package and includes splined sleeve 22098612 — that sleeve is available separately if only it has failed, so confirm what actually needs replacing before ordering the full kit
- At just under 5 kg, support the housing while starting the fasteners, and check driveshaft alignment once assembled
🔄 Supersession & Cross Reference
OEM Supersession Chain
- 22175328 → Supersedes 3863187 → Supersedes 3862265
OEM / Related Numbers
- 3863187 earlier number superseded by this part
- 3862265 earlier number superseded by this part
- 22175326 - included extension housing
- 22098612 - included splined sleeve
- 3862245 - included seals
- 925096 - included seals
- 977910 - included shim range
- 977911 - included shim range
- 977912 - included shim range
📦 Condition
- Genuine Volvo Penta part
- Brand new
- Supplied in original or equivalent packaging
