22178247 Pipe | Genuine Volvo Penta Part

🔧 Product Description

Rigid oil-fill and dipstick guide pipe used in large Volvo Penta industrial-engine lubrication installations. The tube sets the dipstick datum and provides the correct fill path into the sump without contacting rotating components.

🚤 Compatibility

Typically suits:

• Volvo Penta TAD552VE
• Volvo Penta TAD1180-83VE
• Volvo Penta TAD580-83VE
• Volvo Penta TAD570-72VE
• Volvo Penta TAD570-71VE-B
• Volvo Penta TAD550-51VE
• Volvo Penta TAD540-42VE
• Volvo Penta TAD1170-72VE
• Volvo Penta TAD1150-52VE
• Volvo Penta TAD1140-42VE

• Engine Family: TAD
• Serial Range: SN-70112030264

⚙️ Key Features

• Correct bore and wall thickness for the assigned medium
• Designed for original seals, clamps, brackets and mating fittings
• Exact schematic position and serial-controlled configuration must match from serial number 70112030264

🔌 Function

Guides the oil dipstick to the calibrated sump position and provides a clean engine-oil filling path.

⚠️ Common Signs of Failure

• External leakage, staining or pressure loss
• Cracking at bends, welds, flares or brazed joints
• Kinking, crushing or internal restriction
• Fretting or misalignment at supported connections

🛠️ Service Notes

• Offer the pipe up and check it reaches both connections freely before you tighten anything — a rigid pipe pulled into place is a pipe left under permanent strain, and strained pipes crack at the fittings in service
• Renew the sealing washers, O-rings or union seals that go with the pipe rather than reusing the old ones, and make sure the seats, faces and threads are clean
• Keep the ends capped while you work and blow or flush a pipe through before fitting; anything left inside goes straight into the oil, fuel or coolant system
• Tighten unions and banjo bolts evenly to the figures in the workshop manual for your engine — overtightening distorts the seat and starts the leak you were trying to cure
• Refit every clip and support bracket in its original place and keep the pipe clear of hot or moving parts so it cannot chafe or be shaken to failure

🔄 Supersession & Cross Reference

OEM / Related Numbers

• 23684459 - later/related oil-fill pipe
• 22178249 - associated oil-dipstick references
• 23681401 - associated oil-dipstick references
• 975371 - retaining screw
• 21517690 - associated gaskets
• 18813 - associated gaskets

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
