22187882 Wiring Harness | Genuine Volvo Penta Part

🔧 Product Description

EVC-E interface harness used to connect engine/drive data, pickup tachometer or MultiLink network components within Volvo Penta electronic marine-control systems. Connector keying and communication topology are system-generation specific.

🚤 Compatibility

• Engine Family: D, TAD

Full model list at the end of this description.

⚙️ Key Features

• Factory connector keying, pin allocation and branch lengths
• Wire gauges and shielding matched to the assigned circuits
• Protective sleeving designed for engine heat, oil and vibration
• Correct breakout points prevent strain at sensors and actuators
• Product number, serial number and control-system generation must match

🔌 Function

Carries engine-speed or network communication signals between the monitored component and the EVC-E control/instrument system.

⚠️ Common Signs of Failure

• Gearbox oil pressure or temperature alarms appearing intermittently
• Shift or gear-monitoring signals dropping out, often worse once the box is hot
• The loom chafed where it runs between the engine and the gearbox
• Connector pins oil-soaked, corroded or pushed back in the housing
• Faults that change when the cable is moved by hand with the engine running

🛠️ Service Notes

• This is the transmission cable for a D13 with an inboard ZF reverse gear - 22191290 is the equivalent D11 cable, so order by engine and gearbox rather than by appearance
• It supersedes 21769586
• Check the gearbox sender itself and its earth before condemning the cable, and support the loom clear of the bellhousing where it crosses

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 22187882 → Supersedes 21769586

OEM / Related Numbers

• 21769586 earlier number superseded by this part
• ZF400A reverse-gear electrical installation may use this harness in the monitored-speed circuit

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta D13C1-A MP, D13C2-A MP, D13C3-A MP, D13C4-A MP, D13B-L MP, D13B-E MH, D13B-E MH (FE), D13B-K MP, D13B-N MH, D13B-N MH (FE), D13B-B MP, D13B-J MP, D13B-M MP, D13C6-A MP, D13C1-A MH, D13C2-A MH, D13C5-A MP
• Volvo Penta D11B3-A MP, D11B4-A MP, D11B2-A MP, D11B1-A MP
• Volvo Penta D16C-A MH, D16C-B MH, D16C-C MH, D16C-D MH
• Volvo Penta D9A2L MH, D9A2M MP
• Volvo Penta TAD1240GE
• Volvo Penta TAD1241GE
• Volvo Penta TAD1242GE
