22206133 Plane Gasket | Genuine Volvo Penta Part

🔧 Product Description

High-temperature flat gasket used at a turbocharger oil-feed, oil-return or exhaust-adjacent flange. It seals the rigid line/flange under hot engine-oil exposure and continuous thermal cycling.

🚤 Compatibility

Typically suits:

• Volvo Penta D6-440I-G
• Volvo Penta D6-480I-G
• Volvo Penta D6-440I-WJ-G
• Volvo Penta D6-480I-WJ-G
• Volvo Penta D6-440D-G
• Volvo Penta D6-480D-G
• Volvo Penta D6-400A-G
• Volvo Penta D6-440A-G
• Volvo Penta TAD1170-72VE
• Volvo Penta TAD1150-52VE
• Volvo Penta TAD1140-42VE
• Volvo Penta D6-480A-G

• Engine Family: D, TAD
• HP Range: 400-480 HP

⚙️ Key Features

• Oil- and heat-resistant gasket material
• Precision port and bolt-hole alignment
• Designed for the specified turbo oil flange
• Single-use replacement during turbo/line service
• Mating faces must be flat, clean and correctly torqued
• Also supersedes Volvo part numbers 848026, 876005, 876318, 876564, 876610, 876936 and 877104

🔌 Function

Seals the turbocharger oil-line flange to prevent oil loss and air entry while tolerating high temperature.

⚠️ Common Signs of Failure

• Oil seepage or smoke around the turbo flange
• Low turbo oil supply or drain leakage
• Gasket blowout from warped flanges
• Coking and heat damage around the joint
• Turbo bearing damage following oil loss

🛠️ Service Notes

• Always fit a new gasket, and take the old one off completely without scoring the joint faces — a plastic scraper and a residue-free solvent on aluminium, never an abrasive disc or a steel blade
• Check both faces for flatness, corrosion pitting and pulled threads before assembly; a gasket cannot bridge a distorted or damaged joint face
• Fit dry unless the procedure for your engine specifically calls for sealant — sealant on a gasket designed to run dry acts as a lubricant and lets the gasket creep out under clamping load
• Locate the gasket on its dowels or bolts and check every port, passage and bolt hole lines up before anything is tightened
• Draw the fasteners down in stages, evenly and from the centre outwards, to the figure in the workshop manual for your engine
• Handle the gasket flat and unfolded — a crease or a nicked edge becomes a leak path

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 22206133 → Supersedes 420641 → Supersedes 1545143

OEM / Related Numbers

• 420641 earlier number superseded by this part
• 420475 earlier number superseded by this part
• 417378 earlier number superseded by this part
• 466393 earlier number superseded by this part
• 876107 earlier number superseded by this part
• 1545143 earlier number superseded by this part
• 20781146 - related turbo/manifold gaskets
• 20707685 - related turbo/manifold gaskets
• 22281111 - exhaust manifold
• 21867994 - pressure hose
• 21831612 - oil-return pipe
• 420643 - legacy related gasket references in older engine families; confirm application

OEM Reman Alternatives

• 3801560 - related remanufactured turbocharger

Aftermarket / Verified Equivalents

• RECMAR REC22206133 - aftermarket gasket cross-reference
• FA1 455-547 - aftermarket gasket cross-reference

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
