22227295 Volvo Penta Gear Housing Complete Lower Unit DPS-D1 2.32 | Genuine Used Part

🔧 Product Description

Genuine Volvo Penta DPS DuoProp Complete Lower Gear Housing - Part Number: 22227295

A genuine Volvo Penta complete lower gear housing for DPS-B1, DPS-D and DPS-D1 DuoProp sterndrives.

This unit was supplied as a DPS-D1 2.32:1 application. The lower gear housing itself is shared across 1.95:1, 2.14:1 and 2.32:1 drive configurations, with the final overall reduction determined by the matched upper gear housing.

The assembly uses two counter-rotating propeller shafts to improve acceleration, low-speed handling, directional stability and propeller grip.

⚙️ Key Features

• Genuine Volvo Penta complete DuoProp lower unit
• Correct current part number 22227295
• Suitable for DPS-B1, DPS-D and DPS-D1 drives
• Spiral-spline twin-propeller shaft arrangement
• Shared lower housing for 1.95, 2.14 and 2.32 overall ratios

🚤 Compatibility

Commonly used on

• Volvo Penta DPS-B1 DuoProp sterndrives
• Volvo Penta DPS-D DuoProp sterndrives
• Volvo Penta DPS-D1 DuoProp sterndrives

Typically suits

• Drive configurations:
• DPS-B1 1.95:1
• DPS-B1 2.14:1
• DPS-B1 2.32:1
• DPS-D 1.95:1
• DPS-D 2.14:1
• DPS-D 2.32:1
• DPS-D1 2.32:1
• Volvo Penta V6 and V8 petrol sterndrive packages using the DPS-B1, DPS-D or DPS-D1 platform
• Volvo Penta diesel sterndrive packages factory-fitted with the applicable DPS drive
• HP Range: Approximately 200HP - 380HP, dependent on matched drive and engine package
• Drive Type: Twin-propeller DuoProp sterndrive lower unit
• Gear Ratio: Removed from a 2.32:1 drive; lower housing also supports 1.95:1 and 2.14:1 configurations
• Year Range: Approximately mid-2000s onward, dependent on drive model and serial number

🔌 Function

The lower gear housing transfers power from the vertical driveshaft through the bevel gears to two counter-rotating propeller shafts. The opposing propeller rotation reduces steering torque and improves thrust, manoeuvrability and acceleration.

⚠️ Common Signs of Failure

• Milky or contaminated gear oil from water intrusion
• Gear or bearing noise under load
• Propeller shafts have excessive movement or runout
• Oil leakage around the propeller-shaft seals
• Damaged skeg, cavitation plate or gear-housing casting

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 22227295 current complete lower gear-housing reference
• 21658892 earlier and remanufactured lower-unit reference

OEM / Related Numbers

• 22227295
• 21658892
• DPS-B1
• DPS-D
• DPS-D1
• Volvo Penta IH-series aluminium propellers
• Volvo Penta FH-series stainless-steel propellers

Aftermarket / Verified Equivalents

• Volvo Penta Exchange / Remanufactured: 21658892
• Specialist remanufactured lower unit: 22227295 / 21658892
• No direct aftermarket replacement casting

📦 Condition

• Genuine used part
• Removed from running drive where applicable
• In good working condition unless otherwise stated
