22231113 Bracket | Genuine Volvo Penta Part

🔧 Product Description

Structural support bracket used around the turbocharger and oil-line assembly on a Volvo Penta heavy-duty diesel engine. It supports the turbocharger or related pipework and limits fatigue loading at oil and exhaust connections.

🚤 Compatibility

Typically suits:

• Volvo Penta D11C1-A MP
• Volvo Penta D11C3-A MP
• Volvo Penta D11C2-A MP
• Volvo Penta D11C4-A MP
• Volvo Penta D11B3-A MP
• Volvo Penta D11B4-A MP
• Volvo Penta D11B2-A MP
• Volvo Penta D11B1-A MP

• Engine Family: D

⚙️ Key Features

• Turbocharger and oil-line support
• Heavy-duty factory bracket geometry
• Related to clamp 22651629
• Used with turbochargers 3801526 / 21589237
• Supports oil line 23437100
• Engine type: 13-litre 6-cylinder turbocharged diesel

🔌 Function

Supports turbocharger-related mass and pipework so vibration and exhaust loads are not carried by oil or exhaust joints.

⚠️ Common Signs of Failure

• Cracked bracket or mounting ear
• Turbocharger movement
• Repeated oil-line or V-clamp failure
• Exhaust leak from misalignment

🛠️ Service Notes

• Offer the bracket up and start every fastener by hand before tightening any of them, so the component is not pulled into a strained position
• Check the mating faces are clean, flat and free of corrosion scale — a bracket that does not sit flat will work loose and let the component move
• Renew self-locking nuts, lock washers, tab washers or thread-locking compound wherever the original assembly used them, and tighten to the figure given in the workshop manual for your engine
• Where the bracket carries a rubber mount or bush, renew that at the same time rather than reusing a perished one
• On brackets in the inlet and exhaust area, never force alignment to make the holes line up — cure the misalignment at its source, or the bracket and the component it holds will both crack

🔄 Supersession & Cross Reference

OEM / Related Numbers

• 22651629 (attaching clamp)
• 3801526 (related turbochargers)
• 21589237 (related turbochargers)
• 23437100 (related oil line)

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
