22235858 Charge Air Pipe | Genuine Volvo Penta Part

🔧 Product Description

Rigid charge-air pipe used in the TAD1140-TAD1172VE cooling and air-inlet package. It connects charge-air hoses and the cooler while maintaining the designed boosted-air flow path.

🚤 Compatibility

Typically suits:

• Volvo Penta TAD1170-72VE
• Volvo Penta TAD1150-52VE
• Volvo Penta TAD1140-42VE

• Engine Family: TAD

⚙️ Key Features

• TAD11 charge-air system application
• Rigid factory pipe geometry
• Works with hoses 22235933 and 22235952
• Supported by brackets 22201811 / 22354698
• Maintains boost flow and clearance
• Engine type: 11-litre 6-cylinder turbocharged industrial diesel

🔌 Function

Carries compressed air between the turbocharger, charge-air cooler and intake manifold.

⚠️ Common Signs of Failure

• Boost leak
• Cracked weld or pipe
• Oil mist at hose joints
• Reduced power and black smoke
• Pipe movement from failed brackets

🛠️ Service Notes

• Clean both sealing faces before assembly and check the rubber sleeves, seals and clamps; hardened, swollen or split sleeve rubber will not hold boost on a new pipe
• Seat the pipe fully onto its spigots and set each clamp behind the bead before tightening, so pressure cannot push the joint apart
• Align and support the pipe on its brackets so it is not pulled into tension — a pipe held under strain chafes, cracks and works its clamps loose
• Check the bore for oil sludge and soot before fitting and clean it out; carried-over oil softens sleeve rubber and blackens a new pipe from the inside
• Tighten clamps and any flange fasteners to the figures in the workshop manual for your engine, then re-check them after the first run under load

🔄 Supersession & Cross Reference

OEM / Related Numbers

• 22235933 (related hoses)
• 22235952 (related hoses)
• 865127 (charge-air hose)
• 22201811 (brackets)
• 22354698 (brackets)
• 21851231 (fan ring)
• 22085505 (spacer sleeve)

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging
