22257086 Frame | Genuine Volvo Penta Part

🔧 Product Description

Genuine Volvo Penta Cooling-Package Frame - Position B - Part Number: 22257086

Second structural frame in the Volvo Penta TAD1640GE-B, TAD1641GE-B and TAD1642GE-B heavy-duty cooling package. It is matched to the other frame, radiator, charge-air cooler, shroud and seal components.

⚙️ Key Features

• Exact TAD1640-TAD1642GE-B application

• Heavy-duty integrated cooling-package design

• Matched to radiator and charge-air cooler geometry

• Uses seals 22257079 and 22257082

• Factory frame and shroud mounting

🔄 Supersession & Cross Reference

OEM Supersession Chain:

• 22257086 (current OEM reference)

OEM / Related Numbers:

• 22257086

• 22257084 (charge-air cooler)

• 22257085 (radiator)

• 22257083 / 22257086 (frames)

• 23122124 (fan shroud)

• 22257079 / 22257082 (seals)

• 948885 (gasket)

• 1676622 (quick coupling)

• 476279 (protecting cap)

• 984733 (flange screw)

• 947043 (hose nipple)

Aftermarket / Verified Equivalents:

• No aftermarket equivalent

🚤 Compatibility

Commonly used on:

• Volvo Penta D16 generator-engine cooling package

Typically suits:

• Engine models:

• TAD1640GE-B, TAD1641GE-B, TAD1642GE-B

• Engine Type: 16-litre 6-cylinder turbocharged generator diesel

• Engine Models: TAD1640GE-B, TAD1641GE-B and TAD1642GE-B

• Serial Range: Confirm cooling-package and fan-shroud revision

🔌 Function

Supports and aligns the opposite side of the radiator, charge-air cooler and shroud.

Common signs of failure:

• Cracked frame

• Loose core mounting

• Fan/shroud misalignment

• Vibration damage

• Corrosion around fasteners

📦 Condition

• Genuine Volvo Penta part

• Brand new

• Supplied in original or equivalent packaging
