22287141 Stud | Genuine Volvo Penta Part

🔧 Product Description

Ground stud used in the engine-harness installation, identified in the Volvo Penta parts section as the ground point near the port cam-sensor lead. It provides a dedicated threaded chassis/engine earth connection.

🚤 Compatibility

• Engine Family: V
• HP Range: 200-430 HP

Full model list at the end of this description.

⚙️ Key Features

• Engine-harness ground point
• Located near the port cam-sensor lead in the documented harness section
• Factory thread and stud length
• Supports low-resistance sensor and harness grounding
• Critical electrical reference connection
• Engine type: Electronically controlled Volvo Penta engine
• L=85mm (Volvo assembly listing)
• Quantity varies by assembly, most commonly three

🔌 Function

Provides the low-resistance engine/chassis ground point for the harness and sensor circuits.

⚠️ Common Signs of Failure

• Intermittent sensor faults
• Poor starting or control-unit resets
• Corrosion at ground eyelets
• Loose earth connection
• Voltage measured between engine and battery negative

🛠️ Service Notes

• Clean and chase the female thread before fitting so the stud can pull down square and to full depth
• Screw studs in with a proper stud installer or the double-nut method; gripping the plain shank with pliers or self-grips scores it and the nut will never seat or torque correctly afterwards
• Screw the stud home until it seats as the manual for your engine describes, and no further — a stud wound in hard to cure a slack thread will simply split the casting
• Renew studs that are stretched, necked, bent or corroded rather than reusing them; exhaust and manifold studs in particular are cheap next to the work of extracting a broken one
• Tighten the nuts to the torque figures and in the sequence given in the workshop manual for your engine, and where a stud passes into an oil or coolant space seal it as the manual specifies

🔄 Supersession & Cross Reference

OEM Supersession Chain

• 22287141 → Supersedes 3857937

OEM / Related Numbers

• 3857937 earlier number superseded by this part

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta V8-350-C-R, V8-350-CE-R, V8-380-C-R, V8-380-CE-R, V8-430-C-R, V8-300-C-M, V8-300-CE-M, V8-350-C-M, V8-350-CE-M, V8-300-C-N, V8-300-CE-N, V8-350-C-N, V8-350-CE-N, V8-380-C-M, V8-380-CE-M, V8-380-CE-A, V8-380-C-B, V8-380-CE-B, V8-380-C-D, V8-380-CE-D, V8-430-CE-D, V8-350-C-D, V8-350-CE-D, V8-380-C-A, V8-380-CE-J, V8-380-C-J, V8-430-CE-J, V8-430-C-J, V8-350-C-H, V8-350-CE-H, V8-350-C-J, V8-350-CE-J, V8-300-C-R, V8-300-CE-R, V8-430-CE-R, V8-430-C-M, V8-430-CE-M, V8-300-C-K, V8-300-CE-K, V8-350-C-K, V8-350-CE-K, V8-380-C-K, V8-380-CE-K, V8-430-C-K, V8-430-CE-K, V8-300-C-P, V8-300-CE-P, V8-350-C-P, V8-350-CE-P, V8-380-C-P, V8-380-CE-P, V8-430-C-P, V8-300-CE-G, V8-300-C-G, V8-300-C-H, V8-300-CE-H, V8-300-C-J, V8-300-CE-J, V8-350-C-G, V8-350-CE-G, V8-380-C-N, V8-380-CE-N, V8-430-C-N, V8-430-CE-N, V8-430-CE-P, V8-300-C-S, V8-300-CE-S, V8-350-C-S, V8-350-CE-S, V8-400-CE-R
• Volvo Penta V6-200-N, V6-200-C-N, V6-200-CE-N, V6-240-M, V6-240-C-M, V6-240-CE-M, V6-280-M, V6-280-C-M, V6-280-CE-M, V6-280-J, V6-280-CE-J, V6-280-G, V6-280-C-G, V6-280-CE-G, V6-280-C-J, V6-240-N, V6-240-C-N, V6-240-CE-N, V6-280-N, V6-280-C-N, V6-240-CE-K, V6-280-CE-K, V6-200-P, V6-200-C-P, V6-200-CE-P, V6-250-P, V6-250-C-P, V6-250-CE-P, V6-280-P, V6-280-C-P, V6-280-CE-P, V6-200-C-G, V6-200-G, V6-200-J, V6-200-C-J, V6-280-CE-N, V6-200-M, V6-200-C-M, V6-250-O, V6-250-C-O, V6-250-CE-O, V6-240-C-G, V6-240-CE-G, V6-240-G, V6-240-J, V6-240-CE-J, V6-240-C-J, V6-200-R, V6-200-C-R, V6-250-R, V6-250-C-R, V6-250-CE-R, V6-280-R, V6-280-C-R, V6-280-CE-R
