22300362 Plug | Genuine Volvo Penta Part

🔧 Product Description

Threaded plug used to close a machined Volvo Penta engine or propulsion-system port. Its thread, length, sealing method and pressure rating are specific to the housing and must be matched to the original position.

🚤 Compatibility

• Engine Family: V
• HP Range: 200-280 HP

Full model list at the end of this description.

⚙️ Key Features

• Factory thread and head geometry
• Closes a pressure or service port
• Uses the specified sealing ring or thread seal
• Designed for engine temperature and vibration
• Fitment controlled by housing and serial number
• Engine type: Volvo Penta marine or industrial engine/propulsion system

🔌 Function

Closes the assigned drilled passage or service opening and retains the system fluid or pressure.

⚠️ Common Signs of Failure

• Rounded drive head
• Corrosion or seizure
• Missing or damaged sealing element

🛠️ Service Notes

• Clean the threads and the seating face before fitting, and make sure the opening itself is clear of old sealant, swarf and corrosion
• Renew the sealing washer or O-ring where one is fitted rather than reusing a flattened one, and only use thread sealant where the workshop manual for your engine calls for it
• Tighten to the figure given in the workshop manual for your engine — plugs in aluminium and other soft castings strip easily, and a plug pulled up hard to cure a leak usually distorts the seat and makes it worse
• Where the plug closes an oil, fuel or coolant passage, run the engine up to temperature afterwards and check the joint under pressure before signing the job off
• Keep removed plugs paired with the holes they came out of during a strip-down — plugs of very similar appearance often differ in thread, reach or sealing type

📦 Condition

• Genuine Volvo Penta part
• Brand new
• Supplied in original or equivalent packaging

🔎 Full Model Compatibility

Typically suits:

• Volvo Penta V6-200-N, V6-200-C-N, V6-200-CE-N, V6-240-M, V6-240-C-M, V6-240-CE-M, V6-280-M, V6-280-C-M, V6-280-CE-M, V6-280-J, V6-280-CE-J, V6-280-G, V6-280-C-G, V6-280-CE-G, V6-280-C-J, V6-240-N, V6-240-C-N, V6-240-CE-N, V6-280-N, V6-280-C-N, V6-240-CE-K, V6-280-CE-K, V6-200-P, V6-200-C-P, V6-200-CE-P, V6-250-P, V6-250-C-P, V6-250-CE-P, V6-280-P, V6-280-C-P, V6-280-CE-P, V6-200-C-G, V6-200-G, V6-200-J, V6-200-C-J, V6-280-CE-N, V6-200-M, V6-200-C-M, V6-250-O, V6-250-C-O, V6-250-CE-O, V6-240-C-G, V6-240-CE-G, V6-240-G, V6-240-J, V6-240-CE-J, V6-240-C-J, V6-200-R, V6-200-C-R, V6-250-R, V6-250-C-R, V6-250-CE-R, V6-280-R, V6-280-C-R, V6-280-CE-R
